Page 10

PRODUCT SPECIFICATIONS

Models

16-Port Switch

Other model not available

Standards

IEEE 802.3u: 100BASE-TX

IEEE 802.3: 10BASE-T

Ports

Sixteen (16) 100BASE-TX/10BASE-T

Media Support

100BASE-TX: Category 5 TP

10BASE-T: Category 3, 4 or 5 TP

Bandwidth

100BASE-TX: 200/100Mbps via Auto-Negotiation

10BASE-T: 20/10Mbps via Auto-Negotiation

Forwarding/
Filtering Rate

148810 packets/second per port @ 100Mbps, maximum

14881 packets/second per port @ 10Mbps, maximum

Latency

8.5

sec @100Mbps, minimum

sec @ 10Mbps, minimum

MAC Addresses

8K Six (6)-byte entries maximum, Self-Learning

Buffer Memory

4M bits

Duplex Modes

Auto-Negotiation

Auto-MDIX

All TP ports support Auto-MDI/MDIX function

DIP Switches

Two (2) for Home VLAN setting

Four (4) for TRUNK setting

LED Indicators

One (1) for Power

One (1) per port for Link/ACT

One (1) per port for Full-Duplex or Collision

Two (2) for Home VLAN status

Four (4) for TRUNK Group status

Power Supply

Internal full range switching power supply

Input voltage: 100 ~ 240V AC +/-10%, 50/60 Hz

Power
Consumption

9.9W maximum

Environment

Operating Temperature: 0

~ 45

C (32

~ 113

Storage Temperature: -20

~ 70

C (-4

~ 158

Humidity: 10% ~ 90% Non-Condensing

Certifications

FCC Class A, CE Mark and TUV approved

Dimensions

250 x 150 x 43 mm (9.8 x 5.9 x 1.7 inches)

FCC WARNING

This equipment has been tested and found to comply with the limits for a Class A computing device pursuant to
Part 15 of FCC Rules, which are designed to provide reasonable protection against electromagnetic interference

in a commercial environment.

Changes or modifications to the equipment not expressly approved by the party responsible for compliance could

void the user's authority to operate the equipment.

CE MARK WARNING

This is a Class A product. In a domestic environment this product may cause radio interference in which case the

user may be required to take adequate measures.
