Page 6
STACK FRAME ASSEMBLY LEGEND
PSBE BACK EXTENSION
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 7541601 WLDMT, PSBE STACK FRAME
2 6 3238101 NUT, BLIND INSERT M10 X 1.5
3 2 3237801 PULLEY, 4.5" OD
4 2 3236601 WASHER, 3/8 SAE SS
5 2 7348101 WASHER, SPACER
6 3 3236206 SCREW, M10 X1.5 45MM
7 1 3236901 NUT, M10 X 1.5 JAM
8 2 7335401 NUT, M10 X 1.5 SOCKET HEAD
9 1 7352401 CAP, END 2 X 4
10 2 7352101 CUSHION, WEIGHT STACK
11 2 7328604 GUIDE ROD, .75 OD SOLID 43.88
12 2 7402301 RETAINER, GUIDEROD
13 2 3240501 M10 X 1.5 HXS NO CUP ST BO
14 2 3232421 RING, BRE .940, 5100-100 ST PP B
15 12 7544202 PAD, DUAL LOCK 250 1.5" X 2.0"
16 1 7353501 ASSY, 300LB STACK
17 2 7388201 FOOTPAD, PS RUBBER
18 2 7606602 COVER, STACK-PRO2 STD
19 1 7445301 LABEL, PSBE PLACARD
20 1 7445401 LABEL, PSBE LOGO PANEL
21 1 7348001 LABEL, LIFE FITNESS LOGO
22 1 7422004 LABEL, 2" ASTM WARN
23 1 7571301 LABEL, SERIAL NUMBER
