Page 18
B-6
OPERATION
B-6
SAE-400 SEVERE DUTY
TYPICAL FUEL CONSUMPTION
The typical fuel consumption of the SAE-400 for vari-
ous operating scenarios is shown below:
Low Idle - No Load
.30 gal./ hr.
1100 RPM
(1.12 L./hr.)
High Idle - No Load
.69 gal./hr.
1800 RPM
(2.61 L./hr.)
Welding Load
1.79 gal./hr.
400 Amps, 40 Volts
(6.76 L./hr.)
Welding Load
2.43 gal./hr.
500 Amps, 40 Volts
(9.19 L./hr.)
Auxiliary Power
.71 gal./hr.
3000VA
(3.68 L./hr.)
