Dimensions, Outside dimensions, Symbols used in this manual – LG L1804R User Manual
Page 5
Service Manual 5
Dimensions
Dimensions
D
W
H
'F
TIMER
POWER
MODE
TEMP
FAN
SPEED
F1 LOW
F2 MED
F3 HIGH
Dry
Timer
Fan
Energy
Saver
Cool
W
mm(inch)
660(25
31
/
32
)
H
mm(inch)
428(16
27
/
32
)
D
mm(inch)
680(26
27
/
32
)
Model
Dimension
HBLG1203R
Outside Dimensions
This symbol alerts you to the risk of electric shock.
This symbol alerts you to hazards that could cause harm to the
air conditioner.
This symbol indicates special notes.
NOTICE
Symbols Used in this Manual
