Technical specifi cations:
TWINDRIVE™ TD1 220:
Ordering example:
Type Spindle
pitch
(mm)
Torsion
max.
(Nm)
Speed at
full load
(Rpm)
Duty cycle
(%)
TD1 220 2.5 220 0,43 10
TD1 280 2.5 280 0,56 10
The above measurements are made in connection with internal control box and are average values.
1 0 1 0 0 0 0 0 0
Mains cut-off: 0 = None
1 = Mains cut-off with EU wall plug, black,
without non detachable cable 3.2 m
2 = Internal mains cut-off
IP degree:
Cable:
0
0 = Straight 3.2 m EU wall plug
3 = Straight 3.2 m UK wall plug
7 = Straight 3.2 m AUS wall plug
9 = Used together with ext. mains cut-off
0 = Standard
Option: 0 = None
Colour:
Emerg. lowering:
Channel:
Angle footrest:
Angle headrest:
Number of motors: 0 = Standard
1 = Only 1 motor for headrest
TD
Mains voltage: 0 = 230 V
A = Standard grey RAL 7035
B = black
0 = None
1 = Emergency lowering via 9V battery
Incl. batteries
0 = None
0 = Standard 45 degrees
0 = Standard 68 degrees
A 0 0
Transformer: 1 = El-core transformer version
Type:
Twist bracket:
1 = TD 1
To be ordered separately
2 = Emergency lowering via 9V battery
Excl. Batteries
Compability with standard handsets:
HB10 HB20 HB20 HB20
Analogue “00” Memory “B1” Memory “C1”
Receiver Transmitter
TD1 220 yes Yes no no
TD1 280 yes yes yes yes
