POWER FEED 10 / R
A-1 INSTALLATION A-1
TECHNICAL SPECIFICATIONS – Power Feed 10 Robotic-K1780-1
WIRE DRIVE OR WIRE DRIVE SECTION OF FEEDER
SPEC.# TYPE LOW SPEED RATIO HIGH SPEED RATIO
Wire Size Wire Size
Speed Solid Cored Speed Solid Cored
K1780-1 Power Feed 10 50-800 IPM .025 - 3/32 in. .035 - .120 in 75 - 1200 IPM .025 - 1/16 in. .035 - 5/64 in.
(1.27-20.3 m/m) (0.6 - 2.4 mm) (0.9 - 3.2 mm) (2.03 - 30.5 m/m) (0.6 - 1.6 mm) (0.9 - 2.0 mm
CONTROL BOX, WIRE DRIVE AND COMPLETE UNITS
SPEC.# TYPE INPUT POWER PHYSICAL SIZE• TEMPERATURE RATING
Dimensions
Height Width Depth Weight Operating Storage
K1780-1 Power 40 VDC 13.5 “ 10.3 “ 12.0 “ 23.5 Lbs -20° to +40° C -40° to +40° C
Feed 10 (340 mm) ( 261 mm) (304 mm) (10.7 Kg)
Wire
Feeder
