4 by 2 format point id reporting code table – Linear DVS-2400 User Manual
Page 43
41
4 BY 2 FORMAT POINT ID REPORTING CODES
STEP #
PROGRAMMING FUNCTION
POSSIBLE 4 BY 2 VALUES
FACTORY 4 BY 2 VALUE
INSTALLATION 4 BY 2 VALUE
210
SENSOR 1 ALARM REPORT CODE
0 - 99
11
211
SENSOR 2 ALARM REPORT CODE
0 - 99
12
212
SENSOR 3 ALARM REPORT CODE
0 - 99
13
213
SENSOR 4 ALARM REPORT CODE
0 - 99
14
214
SENSOR 5 ALARM REPORT CODE
0 - 99
15
215
SENSOR 6 ALARM REPORT CODE
0 - 99
16
216
SENSOR 7 ALARM REPORT CODE
0 - 99
17
217
SENSOR 8 ALARM REPORT CODE
0 - 99
18
218
SENSOR 9 ALARM REPORT CODE
0 - 99
19
219
SENSOR 10 ALARM REPORT CODE
0 - 99
20
220
SENSOR 11 ALARM REPORT CODE
0 - 99
21
221
SENSOR 12 ALARM REPORT CODE
0 - 99
22
222
SENSOR 13 ALARM REPORT CODE
0 - 99
23
223
SENSOR 14 ALARM REPORT CODE
0 - 99
24
224
SENSOR 15 ALARM REPORT CODE
0 - 99
25
225
SENSOR 16 ALARM REPORT CODE
0 - 99
26
226
SENSOR 17 ALARM REPORT CODE
0 - 99
27
227
SENSOR 18 ALARM REPORT CODE
0 - 99
28
228
SENSOR 19 ALARM REPORT CODE
0 - 99
29
229
SENSOR 20 ALARM REPORT CODE
0 - 99
30
230
SENSOR 21 ALARM REPORT CODE
0 - 99
31
231
SENSOR 22 ALARM REPORT CODE
0 - 99
32
232
SENSOR 23 ALARM REPORT CODE
0 - 99
33
233
SENSOR 24 ALARM REPORT CODE
0 - 99
34
234
SENSOR 1 TROUBLE REPORT CODE
0 - 99
41
235
SENSOR 2 TROUBLE REPORT CODE
0 - 99
42
236
SENSOR 3 TROUBLE REPORT CODE
0 - 99
43
237
SENSOR 4 TROUBLE REPORT CODE
0 - 99
44
238
SENSOR 5 TROUBLE REPORT CODE
0 - 99
45
239
SENSOR 6 TROUBLE REPORT CODE
0 - 99
46
240
SENSOR 7 TROUBLE REPORT CODE
0 - 99
47
241
SENSOR 8 TROUBLE REPORT CODE
0 - 99
48
242
SENSOR 9 TROUBLE REPORT CODE
0 - 99
49
243
SENSOR 10 TROUBLE REPORT CODE
0 - 99
50
244
SENSOR 11 TROUBLE REPORT CODE
0 - 99
51
245
SENSOR 12 TROUBLE REPORT CODE
0 - 99
52
246
SENSOR 13 TROUBLE REPORT CODE
0 - 99
53
247
SENSOR 14 TROUBLE REPORT CODE
0 - 99
54
248
SENSOR 15 TROUBLE REPORT CODE
0 - 99
55
249
SENSOR 16 TROUBLE REPORT CODE
0 - 99
56
250
SENSOR 17 TROUBLE REPORT CODE
0 - 99
57
251
SENSOR 18 TROUBLE REPORT CODE
0 - 99
58
252
SENSOR 19 TROUBLE REPORT CODE
0 - 99
59
253
SENSOR 20 TROUBLE REPORT CODE
0 - 99
60
254
SENSOR 21 TROUBLE REPORT CODE
0 - 99
61
255
SENSOR 22 TROUBLE REPORT CODE
0 - 99
62
256
SENSOR 23 TROUBLE REPORT CODE
0 - 99
63
257
SENSOR 24 TROUBLE REPORT CODE
0 - 99
64
4 by 2 Format Point ID Reporting Code Table
