Page 54: Drive
4.
Locate
the
extra
four-wire
power
connector
labelled
P4
and
connect
it
to
the
drive.
Connecting
an
additional
serial
ATA
hard
disk
drive
A
serial
hard
disk
drive
can
be
connected
to
any
available
SATA
connector.
1.
Locate
the
signal
cable
that
comes
with
the
new
drive.
2.
Locate
the
available
SATA
connector
on
the
system
board.
See
3.
Connect
one
end
of
the
signal
cable
to
the
drive
and
the
other
to
the
available
SATA
connector
on
the
system
board.
4.
Locate
one
of
the
extra
five-wire
power
connectors
and
connect
it
to
the
drive.
What
to
do
next:
v
To
work
with
another
option,
go
to
the
appropriate
section.
v
To
complete
the
installation,
go
to
Installing
a
diskette
drive
in
bay
3
To
install
a
diskette
drive
in
bay
3,
do
the
following:
1.
Remove
the
computer
cover.
See
2.
Access
the
system
board.
See
3.
Remove
the
metal
shield
from
the
diskette
drive
bay
by
using
a
flat-blade
screwdriver
to
gently
pry
it
loose.
4.
Remove
the
plastic
panel
in
the
bezel
by
squeezing
the
plastic
tabs
that
secure
the
panel
on
the
inside
of
the
bezel.
5.
Install
a
retainer
bracket
on
the
side
of
the
diskette
drive.
34
User
Guide
