24
START WELDING...
...STOP TINKERING
GRAB THE
Industry's
Best...
PRODUCTUVITY
• No assembly, no
mistakes.
• Designed to maximize
feedability and keep
you welding.
• 100% field serviceable.
EASE-OF-USE
• Interchangeable
components and one
of the industry’s widest
array of parts.
• Rotatable goose necks
provide easy access
to awkward joint
locations.
• Can be connected to
virtually any feeder in
the industry.
PEACE-OF-MIND
• Engineered to integrate
the best features of
your welding machine
and wire.
• Supported by the
industry’s largest
hands-on sales force.
• Don’t be undergunned!
400 400 Amp mp
MIG Gun
400 400 A Amp mp
MIG Gun
400 Amp
MIG Gun MIG Gun
400 Amp
MIG Gun MIG Gun
IN THE 400 AMP MAGNUM ® READY-PAKS ®
Gun Connector
Wire Lincoln Miller ® Tweco ®
Diameter Adapted
.035"-.045" K541-23 K541-21 K541-25
(0.6mm-1.2mm) (Includes K466-1 (Includes K466-3 (Includes K466-2
Connector) Connector) Connector)
.052"-1/16" K541-24 K541-22 K541-26
(1.3mm-1.6mm) (Includes K466-8 (Includes K466-3 (Includes K466-2
Connector) Connector) Connector)
400 AMP EXPRESS™ GUN READY-PAKS ®
15 ft. (4.5m) Gun Cable Length.
Ready-Paks
®
Also Available
In Original 400 amp
Magnum®
Configuration!
• Completely Assembled
• Ready to Weld –
Right Out of the Box!
• Liner And Other Parts
Installed For You!
• Lightweight, Quick and Agile —
All The Muscle Without the Bulk!
• The Pro’s Preferred MIG Gun
• 400 amp, Short Neck, 15 ft. Length
• Heavy Duty Expendable Parts
Ready-Paks
®
Also Available
In Original 400 amp
Magnum®
Configuration!
Ready-Paks Ready-Paks ®
EXPRESS
MIG Gun
Ready-Paks
EXPRES EXPRESS S ™
MIG Gun MIG Gun
