Technical Specifications

(continued)

4.Switch Architecture and Connectivity

Redundant switch fabric (including 160G, 320G and 640G
capacities) and timing unit provides non-blocking connectivity
at AU-4/HO VC-3 and STS-1 level. Concatenation up to
AU-4/4c/16c/64c, STS-1/3c/12c/48c/192c including pipe mode.
15G VC-12/VC-3/VT-1.5 LO-XC adjunct switch fabric
Dual System Controllers (1 + 1) – optional

5.Timing & Synchronization

a. Timing inputs/outputs: DS-1 Telcordia

ITU-T 2Mhz, 2Mbps

b. Timing Quality: Stratum 3
c. System timing references: Reference selection acc. to

ETSI 300417.1.1/ITU-T G.781 and Telcordia

GR253

6.Fault & Performance Monitoring

a. Performance Monitoring:

Telcordia

GR-253-CORE, ITU-T G.784, G.826

b. Local NE alarm indication:

Critical, Major and Minor alarm LED

c. Autonomous alarm forwarding
d. Test access

7.Network Management

a. Transport protocols: OSI, TCP/IP, DCCm and DCCr,

Ethernet communication ports

b. Management Interface: TL-1
c. Management Systems:

Lucent Technologies Optical Craft Interface (OCI),
Navis

Optical Management System

Telcordia

compliant OS

8.Physical Design

a. Sub-rack design: ETSI & GR78 compliant
b. Width: 500mm / 19.7inch

Height: 950mm / 37.4inch
Depth: 545mm / 21.5inch

c. Two systems per ETSI 2.2m and 2.6m rack or GR-63

(NEBS™ 2000) 83.7inch rack

9.Connectors

LC connectors. Conversion solutions to other common
connector types available

10.LambdaUnite

MSS Rack Design

a. LambdaUnite

MSS ETSI-2 rack

600 x 2200 x 600 mm (w x h x d)
23.6 x 86.6 x 23.6 in (w x h x d)

b. LambdaUnite

MSS GR-63:

23.6 x 83.7 x 23.6 in (w x h x d)
(NEBS™ 2000) rack:
600 x 2125 x 600 mm (w x h x d)

c. Earthquake safety standards

Both subrack-rack combinations are certified as defined
for geographic areas labeled as risk zone 4 (GR-63)

11.Power Supply

a. Redundant primary power supply voltage:

–60 / –48V nominal

b. Operation range: –40V to –72V
c. Power consumption: Typical 2500W per NE

12.Environmental Conditions

a. EMC:

EN300 386-2, IEC 61000-4-x series (immunity)
Telcordia

GR-1089-core (emission and immunity)

b. Climate:

System meets ETSI 300 019 requirements on
environmental conditions:
ETSI Class 3.1 on Operation (5°C to 40°C;
short term –5°C to 50°C)
ETSI Class 1.2 on Storage
ETSI Class 2.3 on Transportation
Telcordia

GR-63

(Operating Temp.: 41°F to 104°F;
short term: 23°F to 122°F)

c. Humidity: Operating 5% to 85%; short term 5% to 90%
d. Noise: System complies with ETSI 300 653 and NEBS™ 4.6
e. Laser Safety:

Hazard level 1 or 3A for all circuit packs acc. IEC 60825

13.Product Certifications

CE marking; NEBS™ Level 3 compliant; FDA approval;
UL

listed
