Performance Recessed CFL Downlighting
1001HL
Page 2 of 2
5" Aperture Horizontal Wet Location, CFL, Performance Series, Reflector Trim
Job Information
Type:
26W TRIPLE TUBE LAMP, LUMEN RATING = 1710 LMS, ELECTRONIC BALLAST, CL FINISH TRIM WITH CLEAR LENS
SC = 1.1
CERTIFIED TEST REPORT NO. 3345FR
COMPUTED BY LSI PROGRAM
**TEST-LITE**
150
300
450
600
60˚
30˚
26W TRIPLE TUBE LAMP, LUMEN RATING = 1710 LMS, ELECTRONIC BALLAST, CL FINISH TRIM WITH OPAL LENS
COEFFICIENTS OF UTILIZATION
Ceiling
80%
70%
50%
30%
0
Wall
70 50 30 10 50 10 50 10 50 10
0
RCR
Zonal Cavity Method - Effective Floor Reflectance = 20%
Room
Cavity
Ratio
0 51 51 51 51 50 50 48 48 46 46 43
1 48 47 45 44 46 44 44 42 42 41 39
2 45 43 41 39 42 38 40 38 39 37 35
3 42 39 36 34 38 34 37 34 36 33 32
4 39 36 33 31 35 30 34 30 33 30 29
5 37 33 30 27 32 27 31 27 31 27 26
6 35 30 27 25 30 25 29 25 28 24 23
7 32 28 25 23 27 23 27 22 26 22 21
8 31 26 23 21 25 21 25 20 24 20 20
9 29 24 21 19 24 19 23 19 23 19 18
10 27 22 19 18 22 19 22 17 21 17 17
Determined In Accordance With Current IES Published Procedures
Luminaire Input Watts = 33.0
ZONAL LUMEN SUMMARY
Zone
Lumens
0-10
47.19
10-20
133.79
20-30
178.34
30-40
167.29
40-50
137.02
50-60
60.2
60-70
6.14
70-80
1.07
80-90
.34
90-100
0
100-110
0
110-120
0
120-130
0
130-140
0
140-150
0
150-160
0
160-170
0
170-180
0
COEFFICIENTS OF UTILIZATION
Ceiling
80%
70%
50%
30%
0
Wall
70 50 30 10 50 10 50 10 50 10
0
RCR
Zonal Cavity Method - Effective Floor Reflectance = 20%
Room
Cavity
Ratio
0 48 48 48 48 47 47 45 45 43 43 40
1 45 44 43 42 43 41 42 40 40 39 37
2 43 40 38 37 40 36 38 36 37 35 33
3 40 37 34 33 36 32 35 32 34 31 30
4 37 34 31 29 33 31 32 29 31 28 27
5 35 31 28 26 31 26 30 29 27 26 25
6 33 29 26 24 32 24 28 23 27 23 22
7 31 26 24 22 26 22 26 21 25 21 21
8 29 25 22 20 24 20 24 20 23 20 19
9 27 23 20 18 23 18 22 18 22 18 17
10 26 21 19 17 21 17 21 17 21 17 16
Determined In Accordance With Current IES Published Procedures
Luminaire Input Watts = 33.0
26W TRIPLE TUBE LAMP, LUMEN RATING = 1710 LMS, ELECTRONIC BALLAST, CL FINISH TRIM WITH FRESNEL LENS
ZONAL LUMEN SUMMARY
Zone
Lumens
0-10
51.18
10-20
133.02
20-30
167
30-40
150.81
40-50
17.04
50-60
60.58
60-70
8.93
70-80
1.06
80-90
.14
90-100
0
100-110
0
110-120
0
120-130
0
130-140
0
140-150
0
150-160
0
160-170
0
170-180
0
150
300
450
600
150
300
450
600
60˚
30˚
SC = 0.92
CERTIFIED TEST REPORT NO. 3344FR
COMPUTED BY LSI PROGRAM
**TEST-LITE**
COEFFICIENTS OF UTILIZATION
Ceiling
80%
70%
50%
30%
0
Wall
70 50 30 10 50 10 50 10 50 10
0
RCR
Zonal Cavity Method - Effective Floor Reflectance = 20%
Room
Cavity
Ratio
0 44 44 44 44 43 43 41 41 39 39 37
1 41 40 39 38 39 37 38 36 36 35 33
2 38 36 34 33 36 33 34 32 33 31 30
3 36 33 31 29 32 29 31 28 30 28 27
4 33 30 27 26 30 25 29 25 28 25 24
5 31 27 25 23 27 23 26 22 26 22 21
6 29 25 22 20 25 20 24 20 24 20 19
7 27 23 20 18 23 18 22 18 22 18 17
8 25 21 19 17 21 17 21 17 20 17 16
9 24 20 17 15 19 15 19 15 19 15 14
10 23 18 16 14 18 14 18 14 17 14
13
Determined In Accordance With Current IES Published Procedures
Luminaire Input Watts = 33.0
ZONAL LUMENS AND PERCENTAGES
Zone
Lumens
%Lamp
%Fixt
** Efficiency = 36.6% **
0-30
275.21
16.1
44
0-40
428.79
25.1
68.5
0-60
618.1
36.1
98.7
0-90
626.05
36.6
100
90-120
0
0
0
90-130
0
0
0
90-150
0
0
0
90-180
0
0
0
0-180
626.05
36.6
100
ZONAL LUMEN SUMMARY
Zone
Lumens
0-10
34.84
10-20
98.51
20-30
141.87
30-40
153.58
40-50
129
50-60
60.3
60-70
7.52
70-80
.43
80-90
0
90-100
0
100-110
0
110-120
0
120-130
0
130-140
0
140-150
0
150-160
0
160-170
0
170-180
0
CANDLEPOWER SUMMARY
Angle 0° CP
90° CP
0
369
369
5
365
368
10
360
362
15
349
351
20
332
334
25
309
310
30
280
281
35
247
248
40
208
208
45
168
167
50
124
123
55
62
62
60
22
24
65
4
5
70
1
1
75
1
0
80
0
0
85
0
0
90
0
0
150
300
450
600
100
200
300
400
60˚
30˚
SC = 1.1
CERTIFIED TEST REPORT NO. 3346FR
COMPUTED BY LSI PROGRAM
**TEST-LITE**
1
1
1
CANDLEPOWER SUMMARY
Angle
0° CP
0
486
5
486
10
476
15
457
20
427
25
373
30
312
35
262
40
231
45
208
50
122
55
66
60
19
65
4
70
2
75
1
80
1
85
0
90
0
CANDLEPOWER SUMMARY
Angle
0° CP
0
562
5
545
10
514
15
477
20
423
25
362
30
302
35
248
40
203
45
165
50
125
55
68
60
27
65
6
70
1
75
1
80
1
85
0
90
0
