LG MPE-27 - Manual (Page 4)

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. 4
FRAMING SPECIFICATIONS
Figure 2
Figure 3
FIREPLACE SPECIFICATIONS
Front View Right Side
23 ¹⁄₂"
Top View
⁵⁄₈"
1 ¹⁄₈"
32"
28"
23 ¹⁄₄"
27 ¹⁄₈"
11"
9 ¹⁄₂"
Front View
31 ¹⁄₄"
(794 mm)
Side View
25"
(635 mm)
Note: Framing dimensions are calculated for an in front of the
wall front face installation with finish dry wall in place. 11"
(280 mm)
32"
(833 mm)
25"
(635 mm)
51 ¹⁄₄"
(1302 mm)
22 ¹⁄₂"
(572 mm)
Corner View
4"
(102 mm)
Electrical
Junction
Box
(On Right
Side)
2 x 4
Electrical
Junction
Box
31 ¹⁄₄"
(794 mm)
