Introduction
Physical Details
LEDs - WBR-1100TX
Power On
- Power on.
Off - No power.
Diag On
- Error condition.
Off - Normal operation.
Blinking - This LED blinks during start up.
WAN Act
On - WAN connection is established.
Flashing - Data is being transmitted or received via the WAN port.
LAN: 10
On - LAN connection is using 10BaseT.
Off - No 10BaseT LAN connection.
Flashing - Data is being transmitted or received via the LAN port.
LAN: 100
On - LAN connection is using 100BaseT.
Off - No 100BaseT LAN connection.
Flashing - Data is being transmitted or received via the LAN port.
Wlan Act
On - Wireless connection available; Wireless Access Point is ready for
use.
Off - No Wireless connection available.
Flashing - Data is transmitted or received via the Wireless access point.
This includes "network traffic" as well as user data.
Print Err
On - Printer error detected.
Off - No printer error detected.
Print Act
On - Connection to printer established.
Off - No connection to printer; printer is Off or Off-line.
Flashing - Data is being transmitted to the printer.
LEDs - WBR-1400TX
Power On
- Power on.
Off - No power.
Status (Red)
On - Error condition.
Off - Normal operation.
Blinking - This LED blinks during start up.
LAN
(1, 2, 3, 4)
For each port, there are 2 LEDs
• Link/Act
