43 -
Technical data
Electrical data
Chassis name L 2650
Power supply 220 V -240V/50- 60 Hz
Tuner VHF/UHF/ cable
Hyperband 8 MHz
41 MHz to 860 MHz
Station storage locations 430 / for DVB 1680
TV standards B/G, I, L, D/K, M, N
Colour standard SECAM, PAL, NTSC,
NTSC-V, PAL-V (60Hz)
Sound standard Mono/Stereo/Dual-channel
Nicam B/G, I, L,
Virtual Dolby
Rated audio power 2 x 20 watt
Analogue Teletext TOP/FLOF Level 2.5
Page Memory 3000
Digital Teletext (in UK only) MHEG-5
Connections
Jack 3.5mm Headphones 32- 2000 ohm
Mini-DIN (AVS) Video IN Y/C (S-VHS/Hi 8)
Cinch (yellow) Video IN CVBS (VHS/8 mm)
Cinch (white/red) Audio IN L/R
IEC socket 75 Ohm/5 V/80 mA Antenna/cable/analogue PIP (1 /DVB-T/C
F socket 75 Ohm 13/18 V/350 mA (2 ANT-SAT
EURO-AV 1 Video IN Y/C (S-VHS/Hi 8)
CVBS (VHS/8 mm)
Video OUT CVBS (VHS/8 mm)
Y/C (S-VHS/Hi 8)
Audio IN L/R
Audio OUT L/R
EURO-AV 2 Video IN Y/C (S-VHS/Hi 8)
CVBS (VHS/8 mm)
RGB, YUV
Video OUT CVBS
Y/C, (only with SVHS Link Plus)
Audio IN L/R
Audio OUT L/R
Cinch Audio IN max. 2Vrms Centre
2 x Cinch Audio IN L/R
2 x Cinch Audio OUT (level adjustable in active loud speakers) L/R
Cinch COMPONENT IN: Cb/Pb signal
Cinch COMPONENT IN: Cr/Pr signal
Cinch COMPONENT IN: Y signal
Cinch Digital Audio IN (SPDIF) Digital audio
Cinch Digital Audio OUT (SPDIF) Digital audio
HDMI/DVI Digital Video/Audio IN type A 19pin Digital video and audio
VGA/XGA VGA/XGA IN PC/STB video signal
Mini-DIN Service/L-Link
(1 PIP tuner can be retrofi tted for Individual 32 DVB-T/C and
Individual 32 Selection DVB-T/C.
(2 Digital satellite tuner can be retrofi tted,
Twin sat tuner can be retrofi tted for sets with digital recorder.
Printed in Germany
TB/05/10/1.1
Subject to modifi cations!
© by Loewe Opta 2005
Dolby and the double ´D´ symbol are
trademarks of Dolby Laboratories
