Page 15
B-3
DIMENSION PRINTS
LN-10 / ZIPLINE BOOM PACKAGE
B-3
16 FT. SPRING BALANCED ZIPLINE BOOM ASSEMBLY
N.B.
.81
14.00
12.38
TYP.
88.25
46.00
XA
60.00
60.00
(R 16'-0")
R 192.0
213.6
(17'-10")
18.28
38.25
52.25
17.38
HOLE
FOR 3/4" BOLTING
(4 PLACES)
.81
192.0
183.0
(15'-3")
(16'-0")
N.A.
7.75
UPWARD 50 TO DOWNWARD 6.
46" X 48" OR 60" X 60".
45.00
5.00
15.00
N.B. PALLET BASE IS OPTIONAL. AVAILABLE SIZES ARE
N.A. BOOM ADJUSTS FROM THE HORIZONTAL POSTION
33.00
48.00
TYP.
12.38
.81
MAST PEDESTAL DETAIL
14.00
