POWER MIG
™
300
SERVICE MANUAL
Safety Depends on You
Lincoln arc welding and cutting
equipment is designed and built
with safety in mind. However, your
overall safety can be increased by
proper installation ... and thought-
ful operation on your part. DO
NOT INSTALL, OPERATE OR
REPAIR THIS EQUIPMENT
WITHOUT READING THIS
MANUAL AND THE SAFETY
PRECAUTIONS CONTAINED
THROUGHOUT.
And, most
importantly, think before you act
and be careful.
For use with machine Code Numbers: 10562, 10952, 10958, 11000, 11097, 11098
For use with machine
SVM160-B
April, 2005
• Sales and Service through Subsidiaries and Distributors Worldwide •
Cleveland, Ohio 44117-1199 U.S.A. TEL: 216.481.8100 FAX: 216.486.1751 WEB SITE: www.lincolnelectric.com
• World's Leader in Welding and Cutting Products •
Copyright © 2005 Lincoln Global Inc.
RETURN TO MAIN MENU
Document Outline
- Master Table of Contents
- Safety
- Section A - Installation
- Section B - Operation
- Section C - Accessories
- Section D - Maintenance
- Section E - Theory of Operation
- Section F - Troubleshooting and Repair
- Symptoms
- Major physical or electrical damage is evident.
- Machine is dead - no welding output and no wire feed when gun trigger is pulled.
- No welding output but wire feeds normally when gun trigger is pulled.
- Wire feeds but welding output is low causing wire to “stub”. Welds are “cold”. Machine cannot obtain full rated output of 300 amps at 32 volts.
- The output voltage and wire feed is present continuously or pulsing when gun trigger is NOT activated.
- The output voltage is present continuously when gun trigger is NOT activated. The wire is not feeding.
- No control of arc voltage. Wire feeding is normal.
- There is no gas flow when gun trigger is pulled. Wire feeds and weld voltage is present.
- No control of wire feed speed. Other machine functions are normal.
- There is no wire feed when gun trigger is pulled. Normal open circuit voltage is present.
- The machine stops feeding wire while welding.
- The arc is unstable and or “hunting.”
- Weld bead is narrow or ropy. May have porosity with electrode stubbing into plate.
- The contact tip seizes in the gas diffuser.
- The welding arc is variable and sluggish.
- The arc striking is poor.
- Section G - Electrical Diagrams
