5. LED Description
LED
Color
Function
LINK/ACT
Green
Lit when cable connection is good
and speed is at 100Mbps.
Blinks when any traffic is present.
FDX
Green
Lit when full-duplex mode is active.
6. Wake on LAN
The Wake on LAN function on this adapter can recognize a wake-up frame and
signal the PC to power up.
The default value of WOL (Wake on LAN) function is ON. You can also disable the
WOL function by putting the jumper on the pin 1 and pin 2.
Never drop the jumper, otherwise FNC-0115 will be lack of electricity.
3
2
1
J1
ON
OFF
Wake on LAN select Jumper (J1)
