COMPONENT ASSEMBLY LEGEND ________________________________________
Page 4
PSLR LATERAL RAISE
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 7388701 WLDMT, PSLR MAIN
2 4 3237701 ASSY, PILLOW BLOCK 4.88 X 2.75
3 14 3236801 NUT, M10 HEX NYLOCK SS
4 32 3236601 WASHER, 3/8 SAE SS
5 10 3236204 SCREW, M10 X1.5 35MM
6 4 3237801 PULLEY, 4.5" OD
7 1 7390101 ASSY, PSLR FLOAT PULLEY
8 1 73993xx PAD, 7 X 11-1/4
9 2 7348101 WASHER, SPACER
10 2 7335401 NUT, M10 X 1.5 SOCKET HEAD
11 4 3236206 SCREW, M10 X1.5 45MM
12 1 7352201 CAP, END 1-1/2 X 2
13 3 7352301 CAP, END 2 X 3
14 1 7352401 CAP, END 2 X 4
15 1 7390301 WLDMT, PSLR SHROUD
16 1 7390601 ASSY, PSLR L WORKARM
17 1 7390801 ASSY, PSLR R WORKARM
18 2 3236901 NUT, M10 X 1.5 JAM
19 2 7352001 BUMPER, 2-1/8 X 4-5/8
20 4 3236205 SCREW, M10 X1.5 40MM
21 2 3236217 SCREW, M10 X1.5 100MM
22 4 3236209 SCREW, M10 X1.5 60MM
23 2 7606602 COVER, STACK-PRO2 STD
24 1 7353401 ASSY, 200LB STACK
25 2 7352101 CUSHION, WEIGHT STACK
26 2 7328604 GUIDE ROD, .75 OD SOLID 43.88
27 2 7402301 RETAINER, GUIDEROD
28 2 3232421 RING, BRE .940, 5100-100 ST PP B
29 2 3240501 M10 X 1.5 HXS NO CUP ST BO
30 1 7444101 LABEL, PSLR PLACARD
31 1 7491001 LABEL, PSLR LOGO PANEL
32 1 7348001 LABEL, LIFE FITNESS LOGO
33 2 7422003 LABEL, MOVING PARTS
34 12 7544202 PAD, DUAL LOCK 250 1.5" X 2.0"
35 1 7423801 CABLE, PSLR-2
36 3 7388201 FOOTPAD, PS RUBBER
37 2 3236212 SCREW, M10 X1.5 75MM
38 1 7423703 CABLE, PSLR
39 1 3236902 NUT, M16 X 2 HEX JAM SS
40 6 3238101 NUT, BLIND INSERT M10 X 1.5
41 1 7422004 LABEL, 2" ASTM WARN
42 2 73923xx PAD, FOREARM
43 1 73519xx PAD, SADDLE
44 1 7571301 LABEL, SERIAL NUMBER
45 2 7488701 LABEL, AXIS OF ROTATION
46 3 3237401 PLUG, 7/16" HOLE
47 1 7401801 ASSY, 90 DEG SEAT
