Installation – Lincoln Electric MAGNUM X-TRACTOR 1GX User Manual
Page 8
A-1
INSTALLATION
MAGNUM X-TRACTOR 1GX
A-1
Sales Spec
Input Voltage
Input Current
K173-2
120V, 1ø 50/60 Hz
10 A (light duty, intermittent use)
INPUT
HEIGHT
WIDTH
DEPTH
WEIGHT
14.4” (365 mm)
8.1” (205 mm)
32.5” (825 mm)
34 lbs (15.5 kg)
FILTER LIFE
Approximately 400 lbs. of electrode under normal solid wire GMAW conditions
PHYSICAL DIMENSIONS
Air Flow without a hose
Air Flow with provided hose attached
96 ft
3
/ min (164 m
3
/ hr)
88 ft
3
/ min (149 m
3
/ hr)
VACUUM SPECIFICATIONS
OPERATING SOUND LEVEL
75 dBA
AUTOMATIC SHUT OFF DELAY
5 to 25 seconds (user adjustable)
Technical Specifications- Magnum X-Tractor 1GX
