TEMPERATURE RANGE
OPERATION: - 30 o C o * to +40 o C (- 22 o F to +104 o F)
STORAGE: - 40 o C to +40 o C (- 40 o F to +104 o F)
ENVIRONMENTAL RATING
ENVIRONMENTAL RATING
A-1 INSTALLATION
PIPELINER ® LN-23P
A-1
TECHNICAL SPECIFICATIONS – PIPELINER® LN-23P (K316L-5)
* At temperatures below 0°C, the gun cable may require a warm up operating time to improve flexibility.
OPERATING ARC VOLTAGE
Constant Voltage (CV) 14-50VDC (90VDC Maximum OCV)
RATED CURRENT
250-350 Amps 60% Duty Cycle
(Depending on Gun Used)
WIRE SPEED RANGE
30-170 Inches Per Minute (IPM)
(1.18-6.70 mm)
RECOMMENDED ELECTRODE WIRE SIZES
.068” INNERSHIELD
.072 ” INNERSHIELD
5/64 ” INNERSHIELD
PHYSICAL DIMENSIONS
HEIGHT WIDTH DEPTH WEIGHT
20.5 Inches 9.0 Inches 19.0 Inches 27 lbs
(520.7 mm) (228.6 mm) (482.6mm) (12.3 kg)
PHYSICAL DIMENSIONS
RECOMMENDED ELECTRODE WIRE SIZES
WIRE SPEED RANGE
RATED CURRENT
OPERATING ARC VOLTAGE
