COMPONENT ASSEMBLY LEGEND
HDCR9 HEAVY DUTY 9 FOOT COMBO RACK
ITEM NO.
QTY.
PART NO.
DESCRIPTION
1*
1
HDCR9-RX-0
WDMT, REAR CROSS TUBE
2*
2
HDCR9-CPU-0
PTD ASSY, PULL-UP SUPPORT
3*
2
HDCR9-CFUPL-0
PTD ASSY, 9' COMP FRT UPRIGHT LFT
4*
4
HDCR9-RUP-0
WLDMT, REAR UPRIGHT
5*
2
HDCR9-USF-0
WLDMT, OHDCR, CROSS SUPPORT
6*
2
HDCR9-LSF-0
WLDMT, HDCR9 BASE
7
1
HD-LDL-00
PLATED WDMT, LONG DOCK-LOCK
8*
2
HDCR9-CFUPR-0
PTD ASSY, 9' COMP FRT UPRIGHT RT
9
70
H-BACK-WASH
BACKING WASHER
10
40
WASH.375SAE
3/8" SAE FLAT WASHER
11
20
NUT.375LOCK
3/8" THICK LOCK NUT
12
66
WASH.5STAR
1/2" INTERNAL LOCK WASHER
13
20
HHB.375X4.5
3/8 X 4.5 BOLT
14
56
HHB.5X4.5
1/2 X 4 1/2 BOLT
15
58
NUT.5LOCK
1/2" THICK LOCK NUT
16
2
HHB.5X3.5
1/2 X 3 1/2 BOLT
17
2
HDCR9-CBSR-0
PTD ASSY, BAR SUPPORT RIGHT
18
2
HDCR9-CBSL-0
PTD ASSY, BAR SUPPORT LEFT
19
2
HDCR9-CBCR-0
PTD ASSY, BAR CATCH RIGHT
20
2
HDCR9-CBCL-0
PTD ASSY, BAR CATCH LEFT
21
20
ANG-WT-HORN-ASSY ANGLED WEIGHT HORN
22
2
WARNING LARGE-V
LARGE WARNING VERT.
23
1
SERIAL NUMBER
SERIAL NUMBER
24
1
PATENT
PATENT DECAL
