Figure 14, Figure 13 – Life Fitness Parabody 660 User Manual
Page 11
FIGURE 14
STEP 14
• LOOSEN the bolts holding the TOP BOOM to the UPRIGHTS. Bolts will have to be removed to install GUIDE RODS (1). See
FIGURE 14.
11
0
1
2
3
4
5
6
1/2
1/2
1/2
1/2
1/2
1/2
LOOSEN!
TOP BOOM
LOOSEN!
STEP 13
• Snap two WEIGHT PLATE BUSHINGS (17) each,
into the “ top” side of fifteen WEIGHT PLATES
(16) as shown in FIGURE 13.
16
17
• Slide the WEIGHT PLATE SHAFT (2) thru the
hole in the HEAD PLATE(4), and lock in place
using one 3/4” E-RING (18) as shown in
FIGURE 13.
4
xx
FIGURE 13
18
