Features
• Two voice ports (RJ-11) for
analog phones or fax
machines with two
independent telephone
numbers
• One RJ-45 port for 10Base-T
Ethernet connection
• Supports Dynamic Host
Configuration Protocol (DHCP)
• Supports Session Initiation
Protocol (SIP)
• Supports multiple voice
compression G.711, G.726,
G.729, and G.723.1
• Web-based configuration
through a built-in web server
• Telephone key pad
configuration via voice
prompts
• Supports DTMF tone detection
and generation
• Supports FSK Caller ID, DTMF
Caller ID and FSK VMWI
• Support echo cancellation
and Voice Activity Detection
(VAD)
• Password protected access
and configuration
• Supports auto-provisioning with
remote firmware upgrade
Specifications
Model PAP2
Standards IEEE 802.3 (10BaseT), IEEE 802.3u (100BaseTX)
Ports One 10/100 RJ-45 Network Port,
Two Standard Phone Ports, One Power Port
Cabling Type RJ-45 Ethernet Category 5,
RJ-11 Standard Phone Cable
LEDs Power, Ethernet, Phone1, Phone2
Voice Protocol Session Initiation Protocol (SIP v2)
Voice Codecs G.711 a-law, G.711µ-law, G.726, G.729 A, G.723.1
Ringer Equivalence
Number (REN) 5 REN per RJ-11 port
Ring Frequency 10 Hz - 40 Hz
FXS Port Impedance Eight Configurable Setting Including North America
600 ohms, European CTR21
Ring Voltage 60 - 90 Vrms Configurable
Security Features Password-Protected Administration
Environmental
Dimensions 101 mm x 101 mm x 15 mm
(3.98" x 3.98" x 0.59")
Unit Weight 4.80 oz. (0.14 kg)
Power Input 5V DC 2.0A
Certifications FCC, cUL, CE
Operating Temp. 41ºF to 113ºF (5ºC to 45ºC)
Storage Temp. -13ºF to 185ºF (-25ºC to 85ºC)
Operating Humidity 10% to 90%, Non-Condensing
Storage Humidity 5% to 90%, Non-Condensing
Package Contents
• Phone Adapter
• Power Adapter
• User Guide on CD-ROM
• Network Cable
• Quick Installation
• Registration Card
• SKY NOVA Service Materials
Minimum Requirements
• High-speed Internet connection
(cable/DSL/other)
• Broadband Router or Gateway to share
Internet connection
• Regular analog touch-tone telephone or
fax machine
• CD-ROM drive
