Revision Comments Part Description Part No. Ref.
NUT HEX 5/16-18 PLT 803-008C 29.
NUT HEX 3/8-16 PLT 803-014C 30.
NUT HEX 1/2-13 PLT 803-020C 31.
NUT HEX NYLOCK 5/16-18 PLT 803-084C 32.
NUT HEX LOCK 1/4-20 FLG 803-088C 33.
NUT FLANGE LOCK 3/8-16 PLT 803-209C 34.
WASHER INTERNAL STAR #10 PLT 804-004C 35.
WASHER FLAT 1/4 SAE PLT 804-007C 36.
WASHER LOCK SPRING 5/16 PLT 804-009C 37.
WASHER FLAT 3/8 SAE PLT 804-012C 38.
WASHER LOCK SPRING 3/8 PLT 804-013C 39.
WASHER LOCK SPRING 1/2 PLT 804-015C 40.
WASHER FLAT 5/16 SAE PLT 804-036C 41.
WASHER WAVE SPRING 5/16 804-056C 42.
LID LATCH GRIP 817-033C 43.
DECAL SLOW MOVING-GALV. BACKED 818-055C 44.
BRG INS .75IDX1.85OD SPH LCK 822-040C 45.
FLANGETTE 47 MST 822-041C 46.
24 APS1548, APS1560,APS1572 & APS1586 All Purpose Seeder Seeders 313-354P 04/17/13
Table of Contents Part Number Index
Land Pride Section 3: Box
Box Assembly (continued)
Applies to APS1548, APS1560, APS1572, APS1586
