SPECIFICATIONS - Model T300P Series
Page 26
Flue Size 3” / 76mm Rear
Width, Overall
28 3/4” / 730 mm
Depth, Overall
26 1/2” / 660 mm
Height
28 3/4” / 730 mm
Floor to Rear
Flue Center
8 3/4” / 222 mm
Facing Back of Unit,
Outside Edge of Left Leg
To Center of Rear
Flue Outlet
10 1/2” / 267 mm
Floor to Rear
Outside Air Inlet
10” / 254 mm
Facing Back of Unit
Outside Edge of Left Leg
To Center of Air Inlet
17 1/2” / 445 mm
Floor Protection
+ Front and Sides: 6”/152mm
Requirements Back: Up to 6” / 152mm
Standard Features
Fastfire Self Igniter
Wall Thermostat
(wire included)
Hopper Capacity
50 lbs.
Burn time
♦ 14-34 hours
Fuse, Control Board
5 amp, 25 volt, 3AG*
Fuse, Igniter 6 amp, 125 volt*
Heat Input (Max.)
♦ 13,000-32,000 BTU / hr
Overall Efficiency
85%
Emissions
♦ 0.43 gram / hr (varies w/
size and type of fuel)
EPA exempt
Ship Weight
363 lbs.
Room Air Blower
150 CFM; 1.5 amps,
2175 rpm
Auger Motor
1 RPM; .4 amps
Exhaust Blower
95 CFM: 1.0 amps,
2880 rpm
Note: Dimensions shown are approximations only (+/- ¼”)
BACK VIEW
SIDE VIEW
+ Non-combustible thermal rated floor protection must
be used when installed on carpet (see Floor Protec-
tion, page 5). When installed at clearances less
than 6”, the floor protector is only required to ex-
tend to the wall.
♦ Fuel delivery and burn times will vary depending
on size and type of fuel used. Estimated heat in-
put based on fuel value of 8400 BTU per lb.
* Fuses are rated as fast blow.
Face of door
opening to
stove back
28 3/4”
10 “
10 1/2”
17 1/2”
8 3/4”
26 1/2”
28 3/4”
23”
