Unpacking the Spool Gun
Safety Precautions
– Read "Safety Precautions" in the Operating Manual before
proceeding. Only personnel that have read and understood
the Operating Manual should install and operate this equipment.
– Power source must be turned "OFF" and power leads disconnected
when installing this unit.
Unpacking the Spool Gun
Carefully unpack your Magnum 250 LX Spool Gun and attach the
Barrel Assembly, and make sure you have all of the parts shown
below.
MAGNUM 250 LX - INSTALLATION
CABLE ASSEMBLY 25’
BARREL ASSEMBLY
OPERATOR’S
MANUAL
3
MAGNUM 250 LX - SPOOL GUN
KP14AH-364 Contact Tip 3/64th (1.2mm) Included
KP14H-35 Contact Tip .035 (0.9mm) Installed on Barrel Assembly
KP52FN Gas Diffuser Installed on Barrel Assembly
KP23-50 Gas Nozzle Installed on Barrel Assembly
KP2518-2 Drive Roll (.030 to .035 / 3/64th) Installed
