COMPONENT ASSEMBLY LEGEND
FZAB ABDOMINAL
ITEM NO.
QTY.
PART NO. DESCRIPTION
37
6
3236206
SCREW, M10 X1.5 45MM
1
1
7823001
WLDMT, FZAB FRAME
38
39
3236601
WASHER, 3/8 SAE SS
2
1
7492601
WLDMT, FZAB PIVOT ARM
39
1
7511601
KEY, .375 SQUARE X 1.25
3
1
7764001
WLDMT, FZAB WORK ARM
40
1
7423724
CABLE, FZAB 125-1/4
4
1
7493601
WLDMT, FZAB CAM SPPRT
41
1
3236208
SCREW, M10 X1.5 55MM
5
1
7329101
PLATE, FZ, CAM COVER
42
4
3251204
SCREW, M10 X1.5 X 35MM HEX ZN
6
1
7330501
WLDMT, FZ SEAT SUPPORT
43
7
3236204
SCREW, M10 X1.5 35MM
7
1
72971XX
PAD, SEAT SADDLE
44
1
7690101
BUMPER, SLEEVE - 1 INCH DIA
8
2
74689XX
PAD 18 X 9 CONVEX
45
1
7511505
SPACER, FZ/PS INTERNAL 6.345
9
2
73933XX
PAD, ARM REST
46
16
3236202
SCREW, M10 X1.5 25MM
10
1
7911101
ASSY, SEAT CARRIAGE
47
1
7407502
PIN, LINK
11
1
7776501
SHAFT, .625 X .406 X 1.200
48
5
3236201
SCREW, M10 X1.5 20MM
12
1
7778001
ASSY, FZ ADJUSTER HANDLE
49
1
7425295
BRKT, SEAT INDICATOR
13
2
3104903
1.00" ID 1.25" OD BRONZ BUSHING
50
1
7420301
ASSY, MID TOWER-9
14
2
3232401
RING, RETAINING, EXTERNAL
51
8
3251202
SCREW, M10 X1.5 X 25MM HEX ZN
15
6
3237403
PLUG, 1" HOLE
52
5
3236801
NUT, M10 HEX NYLOCK SS
16
3
3237801
PULLEY, 4.5" OD
53
1
3236902
NUT, M16 X 2 HEX JAM SS
17
1
3239201
SPRING, EXT, .375 X .049 X 2.00
54
2
7326201
CAP, D-TUBE - TOP
18
2
3239101
SCREW, M5X10 PHL PAN TT ST
55
4
3238601
M10X1.5 THREADED INSERT (HEX)
19
2
3243201
BEARING, 6007 BALL
56
1
6757701
CLIP, CABLE 2-7/8 X 1 X 1
20
2
7662902
CAP, GRIP 1.50 OD
57
4
3254703
NUT, M10 X 1.5 HEX ZINC
21
2
7776401
SPACER, FLANGE .406 X .495 X .81
58
1
3236701
WASHER, FENDER 3/8" ID X 1.5" SS
22
2
7662802
RING, GRIP 1.50 OD
59
2
3235601
BEARING, 6205 BALL
23
2
7764401
SPACER, FLANGE
60
1
3236207
SCREW, M10 X1.5 50MM
24
1
7764301
SHAFT, TAPPED 1 DIA X 5.330
61
3
7582501
SPACER, TAPPED 0.75 DIA X 3.25
25
2
8094101
COVER, PULLEY-BOLTED PARTIAL
62
1
7582701
PLATE, FZAB CAM GUARD
26
2
7333801
CAP, SMALL FLOV- END
63
1
7582601
BRKT, FZAB CAM GUARD
27
3
7333901
CAP, LARGE FLOV- END
64
2
3119304
CAP, END 1.00 DIA RD 10-12 GA
28
1
7334001
FOOT, 2.50 X 4.49 FLOV
65
2
3235802
GRIP, SHADOW GRAY, 8.00"
29
1
7340201
COVER, FOOT - STRAIGHT
66
1
7972701
PLACARD, FZAB
30
1
7342201
PLATE, CABLE END
67
1
7524501
LABEL, 1-9 STRAIGHT
31
1
7489301
CAM, FZAB
68
1
7571301
LABEL, SERIAL NUMBER
32
1
7763401
CAM, FOLLOWER FZAB
69
1
7422003
LABEL, MOVING PARTS
33
1
7560601
SHROUD, FZAB CAM
70
1
7422004
LABEL, 2" ASTM WARN
34
1
7419601
COVER, FOOT-20 DEG.
71
1
7508601
LABEL, FZAB LOGO
35
5
7385203
SPACER, .406 X .750 X .500
72
1
7630101
RETAINER, CM/MJ, PULLEY
36
10
7335401
NUT, M10 X 1.5 SOCKET HEAD
73
2
74691XX
COVER, 18 X 9 CONVEX PAD
