Linksys HomeLink Series

Model Number:

PCM200HA

Bus Type:

32-Bit Cardbus

Standards:

HPNA 1.0, 1.1, &2.0 Compatible

Ports:

Two RJ-11 Standard Modular Telephone Ports
(Phone, HomeLink)

Speed:

Up to 10Mbps

Cabling:

Standard Modular Telephone Cable (with RJ-
11 connectors)

Topology:

Daisy Chain

LED Status Lights:

Link, Rx, Tx

Environmental

Power:

3V DC, 180mA, 30mA Sleep Mode

Dimensions:

4.7” x 2.6” x 0.75”

Unit Weight:

1.8 oz.

Certifications:

FCC Class B, CE Mark Commercial

Operating Temperature:

32°F to 122°F (0°C to 50°C)

Storage Temperature:

-4°F to 158°F (-20°C to 70°C)

Operating Humidity:

10% to 85% Non-Condensing

Storage Humidity:

5% to 90% Non-Condensing

Customer Support

Phoneline 10M Integrated PC Card

Specifications

Environmental

NetBEUI
Click the Add button. Select Protocol, then click Add. Under Manufacturer,
highlight Microsoft. Under Network Protocol, highlight NetBEUI. Click
OK. Click OK again if you are done adding components; otherwise, continue
adding the components you need. The computer will begin copying files to
your system. When the installation is complete, you will be asked if you want
to reboot. Click OK.

TCP/IP
Click the Add button. Select Protocol, then click Add. Under Manufacturer,
highlight Microsoft. Under Network Protocol, highlight TCP/IP. Click OK.
Click OK again if you are done adding components; otherwise, continue
adding the components you need. The computer will begin copying files to
your system. When the installation is complete, you will be asked if you want
to reboot. Click OK.

inux, Open Source and Beta Operating System

If you want to have a phoneline network and a phone in one room with just
one phone jack, you can still attach your phone or fax to the jack by using a
telephone jack splitter.

Plug your telephone or fax machine into one of the splitter’s ports, and your
HomeLink Phoneline 10M Integrated PC Card into the other.

Modem and Fax Compatibility
