TOWER ASSEMBLY LEGEND
CMFCO FIXED CROSSOVER
ITEM NO
QTY
PART NO
DESCRIPTION
1
1
7639001
WLDMNT, MJFCO TOWER
2
2
3104903
1.00" ID 1.25" OD BRONZ BUSHING
3
1
7642301
BUMPER, CM/MJ, PLUG
4
1
7636101
ASSY, MJ X-OVER BOTTOM
5
1
7638101
WLDMT, MJ, X-OVER PULLEY
6
2
3241801
WASHER, FLAT 6MM SS
7
1
7641301
SHAFT, CM/MJ, BALL STOP
8
2
3232401
RING, RETAINING, EXTERNAL
9
1
7642101
SHIELD, CM/MJ REAR
10
1
7642201
WLDMNT, CM/MJ STK PULLEY
11
3
3237801
PULLEY, 4.5" OD
12
1
3225005
WASHER, 1.031-1.375-031 SPEC ST ZN
13
3
3232421
RING, BRE .940, 5100-100 ST PP B
14
1
7435301
COLLAR, SHAFT 1.020 ID
15
1
7629201
COVER, CENTER TOP
16
2
7629801
COVER, CENTER BOTTOM
17
2
3236207
SCREW, M10 X1.5 50MM
18
4
7335401
NUT, M10 X 1.5 SOCKET HEAD
19
4
7630101
RETAINER, CM/MJ, PULLEY
20
4
7629901
COVER, PULLEY- BOLTED FULL
21
1
3236206
SCREW, M10 X1.5 45MM
22
7
3236801
NUT, M10 HEX NYLOCK SS
23
1
3236902
NUT, M16 X 2 HEX JAM SS
24
3
7334001
FOOT, 2.50 X 4.49 FLOV
25
3
7340201
COVER, FOOT - STRAIGHT
26
6
3236601
WASHER, 3/8 SAE SS
27
6
3251202
SCREW, M10 X1.5 X 25MM UNS HEX CS ST ZN
28
4
3236501
M4 X 0.7 PHL PAN MS ST ZN
29
2
3240502
M10 X 1.5 X 50 HXS NO CUP ST BO
30
2
7634401
RETAINER, CM/MJ, GUIDEROD
31
2
7328618
GUIDE ROD, .75 OD SOLID 71.50
32
2
7352101
CUSHION, WEIGHT STACK
33
1
7647501
ASSY, 190LB STACK
34
8
3236201
SCREW, M10 X1.5 20MM
35
8
7642001
BRKT, CM/MJ, REAR SHROUD
36
22
3239101
SCREW, M5X10 PHL PAN TT ST
37
2
3236220
SCREW, M10 X1.5 130MM
38
2
7634701
SPACER, CM/MJ, .565 X .815
39
8
7385201
SPACER, .406 X .750 X .250
40
2
7348001
LABEL, LIFE FITNESS LOGO
41
1
7647001
WLDMT, CM/MJ, PLACARD BRKT
42
1
7711501
WEIGHT, 5 LB. ADD-ON
43
1
7733901
LABEL, PLACARD CM/MJ CROSSOVER
44
1
7732202
CABLE, CM/MJFCO
45
1
7744501
LABEL, WEIGHT AT HANDLE
