Technical Data / CE Declaration of Conformity
LINDY Art.No. 52020
Product
LINDY W-LAN 11 Wireless LAN Access Point
Wired Interface
10/100BaseT (RJ-45)
Serial Port
DB9 RS-232 (configuration port)
Wireless Interface
11Mbps Wireless LAN IEEE 802.11/11b
Modulation DSSS (CCK, DQPSK, DBPSK)
Operating Frequency
Europe CE/ETSI: 2.412~2.472 GHz (13 channels)
LINDY Art.No. 52020
Europe France: 2.457~2.472 GHz (4 channels)
LINDY Art.No. 52022
[Europe Spain: 2.457~2.462 GHz (2 channels)]
Speed Options
11M/5.5M/2M/1M, also supports Auto Rate Selections
RF Technology
Direct Sequence Spread Spectrum
Power Supply
DC 12V (External power supply included), < 1200mA
RF Output Power
13 dBm (20mV)
Sensitivity
-84dBm @ 11Mbps, PER < 8* 10-2
Antenna
Integrated dipole antenna
LINDY Art.No. 52022
