CHAKRA Power Amplifiers
Owner’s Manual
English Technical Specification
Technical Specification
* Default setting
Type
Dimensions
Weight
Input connectors
(phono models)
Input connectors
(Balanced models)
Output connectors
Fuse rating
Mains input range
Mains frequency range
Input power - maximum
(Continuous)
Input power - standby
Gain (Phono models).
Adjustable for AKTIV (dB)
Gain (Balanced models).
Adjustable for AKTIV (dB)
Input impendance
Input level for clipping
(Phono models)
Input level for clipping
(Balanced models)
Harmonic distortion
Maximum output power
(per channel)
Load tolerance
Frequency response
Peak output voltage
Two channel power
amplifier
W 381 mm, D 355 mm,
H 80 mm incl. feet
W 15", D 14", H 3"
(approx)
5.2 Kg / 11.4 lbs
RCA phono
XLR
4 mm banana / Binding
post
250 V, T10 A
100-120 Vac
220-240 Vac
50 - 60 Hz
300 W
10 W (Phono)
11 W (XLR)
25.6, 26.6, 27.6, 28.6*,
29.6, 30.6, 31.6, 32.6
19.6, 20.6, 21.6, 22.6*,
23.6, 24.6, 25.6, 26.6
7K5 Ω (phono)
7K8 Ω (XLR)
755 mV rms
1.51 V rms
< 0.01 %
100 W rms into 4 Ω
56 W rms into 8 Ω
Unconditionally stable
into all loudspeaker loads
1.4 Hz to 41 kHz
28.9 V
Three channel power
amplifier
W 381 mm, D 355 mm,
H 80 mm incl. feet
W 15", D 14", H 3"
(approx)
6.0 Kg / 13.2 lbs
RCA phono
XLR
4 mm banana / Binding
post
250 V, T10 A
100-120 Vac
220-240 Vac
50 - 60 Hz
300 W
11 W (Phono)
12 W (XLR)
25.6, 26.6, 27.6, 28.6*,
29.6, 30.6, 31.6, 32.6
19.6, 20.6, 21.6, 22.6*,
23.6, 24.6, 25.6, 26.6
7K5 Ω (phono)
7K8 Ω (XLR)
755 mV rms
1.51 V rms
< 0.01 %
100 W rms into 4 Ω
56 W rms into 8 Ω
Unconditionally stable
into all loudspeaker loads
1.4 Hz to 41 kHz
28.9 V
Four channel power
amplifier
W 381 mm, D 355 mm,
H 80 mm incl. feet
W 15", D 14", H 3"
(approx)
6.3 Kg / 13.9 lbs
RCA phono
XLR
4 mm banana / Binding
post
250 V, T10 A
100-120 Vac
220-240 Vac
50 - 60 Hz
300 W
13 W (Phono)
14 W (XLR)
25.6, 26.6, 27.6, 28.6*,
29.6, 30.6, 31.6, 32.6
19.6, 20.6, 21.6, 22.6*,
23.6, 24.6, 25.6, 26.6
7K5 Ω (phono)
7K8 Ω (XLR)
790 mV rms
1.58 V rms
< 0.01 %
100 W rms into 4 Ω
56 W rms into 8 Ω
Unconditionally stable
into all loudspeaker loads
1.4 Hz to 41 kHz
30.1 V
Five channel power
amplifier
W 381 mm, D 355 mm,
H 80 mm incl. feet
W 15", D 14", H 3"
(approx)
6.5 Kg / 14.4 lbs
RCA phono
XLR
4 mm banana / Binding
post
250 V, T10 A
100-120 Vac
220-240 Vac
50 - 60 Hz
300 W
14 W (Phono)
15.5 W (XLR)
25.6, 26.6, 27.6, 28.6*,
29.6, 30.6, 31.6, 32.6
19.6, 20.6, 21.6, 22.6*,
23.6, 24.6, 25.6, 26.6
7K5 Ω (phono)
7K8 Ω (XLR)
790 mV rms
1.58 V rms
< 0.01 %
100 W rms into 4 Ω
56 W rms into 8 Ω
Unconditionally stable
into all loudspeaker loads
1.4 Hz to 41 kHz
30.1 V
Six channel power
amplifier
W 381 mm, D 355 mm,
H 80 mm incl. feet
W 15", D 14", H 3"
(approx)
6.7 Kg / 14.7 lbs
RCA phono
XLR
4 mm banana / Binding
post
250 V, T10 A
100-120 Vac
220-240 Vac
50 - 60 Hz
300 W
14.5 W (Phono)
17 W (XLR)
25.6, 26.6, 27.6, 28.6*,
29.6, 30.6, 31.6, 32.6
19.6, 20.6, 21.6, 22.6*,
23.6, 24.6, 25.6, 26.6
7K5 Ω (phono)
7K8 Ω (XLR)
790 mV rms
1.58 V rms
< 0.01 %
100 W rms into 4 Ω
56 W rms into 8 Ω
Unconditionally stable
into all loudspeaker loads
1.4 Hz to 41 kHz
30.1 V
Two channel power
amplifier
W 381 mm, D 355 mm,
H 80 mm incl. feet
W 15", D 14", H 3"
(approx)
5.8 Kg / 12.7 lbs
RCA phono
XLR
4 mm banana / Binding
post
250 V, T10 A
100-120 Vac
220-240 Vac
50 - 60 Hz
300 W
16 W (Phono)
17.5 W (XLR)
25.6, 26.6, 27.6, 28.6*,
29.6, 30.6, 31.6, 32.6
19.6, 20.6, 21.6, 22.6*,
23.6, 24.6, 25.6, 26.6
7K5 Ω (phono)
7K8 Ω (XLR)
1.1 V rms
2.2 V rms
< 0.005 %
200 W rms into 4 Ω
111 W rms into 8 Ω
Unconditionally stable
into all loudspeaker loads
1.4 Hz to 41 kHz
41 V
Three channel power
amplifier
W 381 mm, D 355 mm,
H 80 mm incl. feet
W 15", D 14", H 3"
(approx)
6.6 Kg / 14.5 lbs
RCA phono
XLR
4 mm banana / Binding
post
250 V, T10 A
100-120 Vac
220-240 Vac
50 - 60 Hz
300 W
19 W (Phono)
19.5 W (XLR)
25.6, 26.6, 27.6, 28.6*,
29.6, 30.6, 31.6, 32.6
19.6, 20.6, 21.6, 22.6*,
23.6, 24.6, 25.6, 26.6
7K5 Ω (phono)
7K8 Ω (XLR)
1.1 V rms
2.2 V rms
< 0.005 %
200 W rms into 4 Ω
111 W rms into 8 Ω
Unconditionally stable
into all loudspeaker loads
1.4 Hz to 41 kHz
41 V
Four channel power
amplifier
W 381 mm, D 355 mm,
H 80 mm incl. feet
W 15", D 14", H 3"
(approx)
6.9 Kg / 15.2 lbs
RCA phono
XLR
4 mm banana / Binding
post
250 V, T10 A
100-120 Vac
220-240 Vac
50 - 60 Hz
300 W
20 W (Phono)
22 W (XLR)
25.6, 26.6, 27.6, 28.6*,
29.6, 30.6, 31.6, 32.6
19.6, 20.6, 21.6, 22.6*,
23.6, 24.6, 25.6, 26.6
7K5 Ω (phono)
7K8 Ω (XLR)
1.1 V rms
2.2 V rms
< 0.005 %
200 W rms into 4 Ω
111 W rms into 8 Ω
Unconditionally stable
into all loudspeaker loads
1.4 Hz to 41 kHz
41 V
Model C 2100 C 3100 C 4100 C 5100 C 6100 C 2200 C 3200 C 4200
