COMPONENT ASSEMBLY LEGEND ________________________________________
MTSDP DECLINE PRESS
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 7552001 WLDMT, MTDP, BACK FRAME
2 1 7554501 WLDMT, MTDP, BASE FRAME
3 1 7555601 ASSY, MTDP, RIGHT SIDE
4 1 7555201 ASSY, MTDP, LEFT SIDE
5 1 7552801 WLDMT, MTDP, TOP FRAME
6 1 7555701 ASSY, MTDP, SEAT FRAME
7 18 7434001 WASHER, MTS, HAMMER HEAD
8 4 3239317 1/2-13 X 4.25 UNS HEX FHB G5 ZN
9 20 3239311 1/2-13 X 2.75 UNS HEX FHB G5 ZN
10 22 3239505 WSH, .500 IN-D ST ZN
11 24 3102801 NUT, NYLOCK 1/2-13 ST ZN
12 6 7477401 CAP. END, 1-1/2 X 3, 11GA SGRY
13 1 7555301 ASSY, MTDP, LEFT ARM
14 1 7555501 ASSY, MTDP, RIGHT ARM
15 2 M051-00289-A000 HAMMER STRENGTH NAME PLATE
16 2 7422003 LABEL, MOVING PARTS
17 4 0017-00042-1046 2.75 X 9.25 FRAME GUARD
18 4 7388201 Footpad, PS Rubber
19 1 M051-00299-A000 HAMMER PATENT DECAL
20 1 7354001 PAD, BACK 32-1/2 X 11-1/4
21 1 7351901 PAD, SADDLE
22 6 3236601 WASHER, 3/8 SAE SS
23 4 3236204 SCREW, M10 X1.5 35MM
24 2 3236210 SCREW, M10 X1.5 65MM
