13
T E C H N I C A L I N F O R M A T I O N
AV 5105 STEREO
POWER AMPLIFIER
Type Two fully independent channels, isolated from
each other and chassis (earth).
Fully regulated dual power supplies per
channel.
Inputs Dual RCA Phono (Line in/out)
Outputs Four pairs per channel
Protection Fully protected into any load; overload,
over-temperature, full short and overdrive
protection
Remote control Signal-sensing auto switch-on/off for energy
conservation or remote operation
Output power 100W/channel/8Ω, 200W/Channel/4Ω
Input signal 1.05V rms for maximum output
Output voltage 28.3V rms maximum
Gain x27 (28.6dB)
Input impedance 4700Ω
Frequency response (-3dB) 2Hz-50kHz
Output offset <5mV
Signal sense threshold >150µV rms
Mains supply 220V–240V T3.15A antisurge
100V–120V T6.3A antisurge
Standby power <5W
consumption
Maximum input power 800W
Dimensions Height 80mm (inc. feet), width 381mm, depth
355m, weight 6.5kg
