Front Panel (LEDs)
LED Indicators of 8 Pair Port PoE Mid-Span Power Supply
LED
Status
Description
Power On
Power is on.
Off
Power is off.
PD
Link
On
Port is connected to a Power Device
port and supplies 48
Off
No Power Device is connected
Connections
Power Device/Existing Switch to this 8 Pair Port Mid-Span Power Supply
Use Cat. 5 twisted-pair cable from the existing switch to the “Data” input port of this Mid-span
Power Supply, and then connect the “Data + Power” output port to the Power Device, such
as Wireless AP, another switches with PD function…etc.
