Optimax blower, Housing assy, Figure 3 – Little Wonder MAXIMUM OUTPUT BLOWER User Manual
Page 17
ITEM PART NO.
DESCRIPTION
QTY ITEM PART NO.
DESCRIPTION
QTY
17
OPTIMAX
BLOWER
EN
FIGURE 3
HOUSING ASSY
3-1
64141-6
NUT 5/16-18
3
3-2
910041.10 HOUSING-8&9HP
1
(LB800 & LB900)
3-3
910646
LABEL-LW HOUSING 8HP 1
(LB800)
3-3
910647
LABEL-LW HOUSING 9HP 1
(LB900)
3-4
910609
LABEL-WARNING
1
3-5
910503
BLT-WLF 5/16-24 X 3/4
4
3-6
64151-31 LOCKNUT-10-32
7
3-7
910130
SPRING-DEFLECTOR
1
3-8
8-18
RING-RETAINING
3
3-9
910131
KNOB
1
3-10 64002-04 LOCKWASHER-5/16
1
3-11
910121.10 DEFLECTOR-8&9HP SIDE 1
3-12 64139-26 BLT-WLF 10-32 X 5/8
2
3-13 910123.10 DEFLECTOR-8&9HP INT
1
3-14 910132
HANDLE-DEFLECTOR
1
3-15 64151-18 LOCKNUT-3/8-16 2-WAY
1
3-16 64123-252 BLT-HEX 3/8-16 X 5-1/2
1
3-17 910403.10 BRKT-FRT WHL
1
3-18 934
WHEEL-PNEUMATIC
1
3-19 900404
SLEEVE-WHEEL
1
3-20 900405
SPACER-FRT WHL BRKT
2
3-21 934B
BRG-PNEUMATIC WHL
2
3-22 64152-68 SCREW 10-32X5-1/2 HH
5
