14
Instant Broadband TM Series
Dimensions: 7.87 x 5.51 x 1.57 inches
(200 mm x 140 mm x 40 mm)
Unit Weight: 10.58 oz. (0.3 kg)
Power: Input 120V AC, Output 15V DC, 400mA
Certifications: FCC Part 15, FCC Part 68, CSA-03
Operating Temp: 32ºF to 122ºF (0ºC to 50ºC)
Storage Temp: 14ºF to 140ºF (-10ºC to 60ºC)
Operating Humidity: 5% to 90%, Non-Condensing
Storage Humidity: 5% to 90%, Non-Condensing
Environmental Specifications
Model No.: ADSLME1
Standards: IEEE 802.3 (10BaseT), ANSI T1.413 Issue 2,
ITU-T G.dmt (G.992.1), ITU-T G.lite (G.992.2)
Protocol: RFC 1483 Bridge
Ports:
One Console Port
Line One RJ-11 port
LAN One 10Mbps RJ-45 port
Cabling Type: UTP Category 5 or better, standard phone line
cable
Speed (Mbps): Line 10 (Half Duplex)
ADSL Up to 8Mbps (Download Speed)
Up to 800Kbps (Upload Speed)
LEDs Power, Alert, LAN Activity, LAN Link, ADSL Link,
ADSL Tx
ADSL Ethernet Modem
