2
ITEM NO. PART NO. DESCRIPTION MODEL NO.
1 DRH1021 DRAFT HOOD 4” ALL
2 WTR1082 NIPPLE, HOT WATER OUTLET 065-050
3 WTR1013 ANODE ROD MAGNESIUM, HEX HEAD 076-075 to 090-100
3A WTR1046 ANODE ROD ALUMINUM, HEX HEAD 076-075 to 090-100
4 WTR1060 ANODE ROD MAGNESIUM, HEAT TRAP 065-050
4A WTR1044 ANODE ROD ALUMINUM, HEAT TRAP 065-050
5 JKT1055 FLUE BAFFLE 065-050
5 JKT1070 FLUE BAFFLE 076-075 & 080-075
6 WTR1018 DIP TUBE 065-050
6 WTR1100 DIP TUBE 076-075 & 080-075
6 WTR1020 DIP TUBE 085-100 & 090-100
7 MSC1060 RELIEF VALVE EXTENDER ALL
7A RLV1001 TEMPERATURE & PRESSURE RELIEF VAVLE ALL
9 WTR1102 HANDHOLE, CRAB (after serial # LA) 085-100 & 090-100
9A GKT1010 GASKET HANDHOLE 076-075 & 080-075
9A GKT1010 GASKET HANDHOLE (before serial # LA) 090-100
10 BLT1020 BOLT CRAB HANDHOLE (after serial # LA) 085-100 & 090-100
10A WTR1016 HANDHOLE, COVER 076-075 & 080-075
10A WTR1016 HANDHOLE, COVER (before serial # LA) 090-100
11 GKT1009 GASKET HANDHOLE (after serial # LA) 085-100 & 090-100
11A BLT1019 BOLT HANDHOLE WTR1101 076-075 & 080-075
11A BLT1019 BOLT HANDHOLE WTR1101 (before serial # LA) 090-100
12 WTR1103 CLAMP CRAB HANDHOLE (after serial # LA) 085-100 & 090-100
12A WTR1101 HANDHOLE JACKET COVER 076-075 & 080-075
12A WTR1101 HANDHOLE JACKET COVER (after serial # LA) 085-100 & 090-100
13 BLT1021 NUT FOR CRAB HANDHOLE (after serial # LA) 085-100 & 090-100
13A BLT1022 SCREW HANDHOLE JACKET COVER 076-075 & 080-075
13A BLT1022 SCREW HANDHOLE JACKET COVER (after serial # LA) 085-100 & 090-100
14 DRV2508 BRASS DRAIN VALVE ALL
15 TST1127 GAS VAVLE/THERMOSTAT NATURAL (180 degree) 065-050
15 TST1193 GAS VALVE/THERMOSTAT NATURAL (180 degree) 076-075 & 080-075
15 TST1036 GAS VALVE/THERMOSTAT NATURAL (180 degree) 085-100 & 090-100
15A TST1161 GAS VAVLE/THERMOSTAT LPG (180 degree) ALL
16 BNR1243 BURNER ASSEMBLY NAT 065-050
16 BNR1244 BURNER ASSEMBLY LPG 065-050
16 BNR1265 BURNER ASSEMBLY NAT 076-075
16 BNR1242 BURNER ASSEMBLY NAT 080-075
16 BNR1141 BURNER ASSEMBLY LPG 076-075 & 080-075
16 BNR1266 BURNER ASSEMBLY NAT 085-100
16 BNR1142 BURNER ASSEMBLY NAT 090-100
16 BNR1143 BURNER ASSEMBLY LPG 085-100 & 090-100
18 PLT1019 PILOT ASSEMBLY NAT 065-050 - 085-100
18 PLT1022 PILOT ASSEMBLY LPG 065-050 - 085-100
18 PLT1017 PILOT ASSEMBLY NAT 090-100
18 PLT1018 PILOT ASSEMBLY LPG 090-100
20 ORF1023-27 ORIFICE, NAT (#27) 065-050
20 ORF1024-43 ORIFICE, LPG (#43) 065-050
20 ORF1023-22 ORIFICE, NAT (#22) 080-075
20 ORF1024-38 ORIFICE, LPG (#38) 080-075
20 ORF1023-20 ORIFICE, NAT (#20) 090-100
20 ORF1024-37 ORIFICE, LPG (#37) 090-100
23 PLT1112 THERMOCOUPLE ALL
26 JKT1150 DOOR INNER 065-50
26A JKT1151 DOOR INNER 076-075 to 090-100
27 JKT1050 DOOR OUTER 065-050
27A JKT1051 DOOR OUTER 076-075 to 090-100
Please provide model & serial number when ordering parts.
©-11/02-Printed in U.S.A.
