RS-485 Protocol
Data Communication Format
• Data Length: 1 Byte (8 Bit)
• Start/Stop Bit: 1 BIT
• Parity Bit: None
• Baud rate: 9,600 bps
Format
*C.S. = Check Sum
• The data of total 6 bytes is transmitted from the
external RS-485 device to the camera.
• BYTE 6 : The value of Check Sum from ‘BYTE 1 ’
to ‘BYTE 5 ’.
ex) In case of transmission, 0xC5, 0x5F, 0x02,
0x00, 0x0A”
C.S. = 0xC5 +0x5F +0x02 +0x00 +0x0A = 0x0130
therefore, C.S. = 0x30
Commands
• You must send “Stop” command to camera after
sending each command described above.
The “Stop” command is “0xC5, 0x5F, 0x0C, 0x00,
ID, C.S.”.
BYTE 1 BYTE 2 BYTE 3 BYTE 4 BYTE 5 BYTE 6
0xC5 CODE1 CODE2 CODE3 CAM_ID *C.S.
Function Command
(external device → camera)
OSD Menu ON/OFF 0xC5, 0x5F, 0x25, 0x00, ID, C.S.
LEFT Button
0xC5, 0x5F, 0x38, 0x00, ID, C.S.
Right Button 0xC5, 0x5F, 0x39, 0x00, ID, C.S.
Up Button 0xC5, 0x5F, 0x02, 0x00, ID, C.S.
Down Button 0xC5, 0x5F, 0x04, 0x00, ID, C.S.
Menu Button 0xC5, 0x5F, 0x24, 0x00, ID, C.S.
38
