Basic Operation
Lexicon
REAR PANEL OVERVIEW
(continued)
The LX-5 rear panel is pictured above. The LX-7
rear panel is pictured on page 2-4. Both are
identical, except the LX-7 features two additional
channels.
1
8
9
3
6
4
5
2
7
External wiring connected to connectors marked with the
symbol pictured at the right requires installation by an
instructed person or the use of ready-made leads or cords.
WARNING
