Lochinvar CNR(A) 625-080-DF9 thru 726-080-DF9 User Manual
Page 2
ITEM NO.
PART NO.
DESCRIPTION
MODEL NO.
1
PVT1003
BLOWER ASSEMBLY
ALL
2
PVT1030
BLOWER MOUNTING FLANGE
ALL
3
GKT1033
BLOWER GASKET
ALL
4
DRH1170
BLOWER VENT ADAPTER
ALL
6
MSC1097
BULKHEAD FITTING
ALL
7
MSC2933
ALUMINUM TUBING (45”)
ALL
8
JKT1053
FLUE BAFFLE
ALL
9
WTR1085
MAG ANODE ROD
ALL
10
RLV1016
T & P RELIEF VALVE
ALL
11
GLV2849
NIPPLE, 1” X 3”
ALL
12
WRE1052
WIRE HARNESS T-STAT TO BLOWER
ALL
13
WTR1081
NIPPLE SIDE CONNECT HOT & COLD
ALL
14
JKT1200
SENSOR COVER
ALL
15
TST1084
DUAL SENSOR THERMOSTAT
ALL
16
DRV2508
BRASS DRAIN VALVE
ALL
18
BLT1041
BOLT FOR HANDHOLE COVER
ALL
19
WTR1101
HANDHOLE CLEAN OUT COVERPLATE
ALL
20
BLT1040
BOLT FOR HANDHOLE
ALL
21
WTR1016
PLATE HANDHOLE COVER NON-ASME
CNR625-080 THRU 725-080-DF9
21
WTR1039
PLATE HANDHOLE COVER ASME
CNA626-080 THRU 726-080-DF9
22
GKT2101
GASKET, 4 X 6 HANDHOLE ASME
CNA626-080 THRU 726-080-DF9
23
GKT1010
GASKET, 4 X 6 HANDHOLE NON-ASME
CNR625-080 THRU 725-080-DF9
24
VAL1063
GAS VALVE NAT
CNR(A)625(6)-080 THRU
CNR(A)725(6)-080-DF9
24
VAL1065
GAS VALVE LPG
CLR(A)625(6)-080 THRU
CLR(A)725(6)-080-DF9
25
BNR1162
BURNER ASSEMBLY NAT
CNR(A)725(6)-080-DF9
25
BNR1253
BURNER ASSEMBLY NAT
CNR(A)625(6)-080-DF9
25
BNR1163
BURNER ASSEMBLY LPG
CLR(A)725(6)-080-DF9
25
BNR1254
BURNER ASSEMBLY LPG
CLR(A)625(6)-080-DF9
26
ORF1020-25
ORIFICE MAIN BURNER(#25)(9 EACH)
CNR(A)625(6)-080-DF9
26
ORF1020-40
ORIFICE MAIN BURNER(#40)(9 EACH)
CLR(A)625(6)-080-DF9
26
ORF1020-20
ORIFICE MAIN BURNER (#20)(9 EACH)
CNR(A)725(6)-080-DF9
26
ORF1020-37
ORIFICE MAIN BURNER (#37)(9 EACH)
CLR(A)725(6)-080-DF9
27
MAN1021-9
MANIFOLD, NINE ORIFICE BURNER
ALL
28
BNR1059
MAIN BURNER
ALL
29
JKT3003
PILOT SHIELD
ALL
30
PLT1140
PILOT ASSEMBLY NAT.
ALL
30
PLT1121
PILOT ASSEMBLY LPG.
ALL
31
MSC2933 ALUMINUM
TUBING
ALL
32
BLK1040
TERMINAL BLOCK ESB1-4-4
ALL
33
TRF1038
TRANSFORMER
ALL
34
RLY1131
IGNITION CONTROL
ALL
35
PRS1001
PRESSURE SWITCH
ALL
Please provide model & serial number when ordering parts.
©-2/07-Printed in U.S.A.
