A-1
CLASSIC II DEUTZ
A-1
TECHNICAL SPECIFICATIONS - CLASSIC II DEUTZ K1406-( )
Make/Model Description Speed (RPM) Bore x Stroke Starting Capacities
System
Deutz 3 cylinder High Idle 1800 3.58” x 4.13 12VDC battery Fuel: 15gal.
F3L 1011F 28.5 HP Low Idle 1350 (91mm x 105mm) & Starter 57 L
Diesel Engine @ 1700 RPM Full Load 1725
SA-250 Oil: 6.3 Qts.
6.0 L
INPUT - DIESEL ENGINE
RATED OUTPUT - WELDER
HEIGHT WIDTH DEPTH WEIGHT
42.94 in. 24 in. 60 in. 1340 lbs.(608 kg)
(1040 mm) (610 mm) (1524 mm)
OUTPUT - WELDER AND GENERATOR
Duty Cycle Constant Current Volts at Rated Amps
Current Range NEMA Output Rating Auxiliary Power
40-325 Amps 250 amps 30 volts 115/250 VAC
@60% Duty Cycle 3kVA
60% Duty Cycle
PHYSICAL DIMENSIONS
40 % 300 amps (DC ) 32 volts
60 % 250 amps (DC ) 30 volts
100 % 200 amps (DC ) 28 volts
INSTALLATION
