Gas Supply Pressure Recommendations:
Gas Type Supply (Inlet) Pressure (mbar)
Recommended
Minimum
Gas Pipe Size
Natural 9-14” WC (2.2 kPA / 22.4 mbar - 3.5kPa / 34.9 mbar) 2” (51 mm)
LP 11-14” WC (2.7 kPa / 27.36 mbar - 3.5 kPa / 34.9 mbar) 2” (51 mm)
*Gas supply pressures are dependent on local gas type and on all applicable local codes. Agency approved flexible
connection to each oven must be minimum¾” (19 mm) NPT and length must not exceed six (6) feet (1829 mm).
Electrical Service:
Each oven deck requires voltage, phase and hertz as indicated by model number. Neutral must be grounded
at electrical service and receptacle properly polarized. Gas 120V units have a cord with NEMA 5-15 plug.
All other models have terminal block connections. It is recommended that a separate circuit breaker be
provided for each oven deck.
Recommended Minimum Clearances:
Rear of oven to combustible surface: 6” (152 mm). Clearance on each side from other cooking equipment: 24”
(610 mm). Clearance required to remove conveyor for cleaning: 11’ (3553 mm).
Warranty:
All new impinger ® ovens installed in the United States and Canada come with a one (1) year parts and labor
warranty starting from the date of start-up/check-out. All ovens installed in locations other than the US and
Canada are warranted for one (1) year parts and ninety (90) days labor starting from the date of start-up/
check-out. Start-up/check-out must occur within 24 months of date of manufacture.
General Information:
All 1600 Models
Length Depth
Height
Single
Height
Double Stacked
Height
Triple Stacked
80”
(2032 mm)
60 ¹/₂”
(1537 mm)
44 ¹/₈”
(1121 mm)
63 ³/₈”
(1610 mm)
66 ³/₈”
(1686 mm)
Model
Number
Agency Utility Input Rate Voltage Hertz Phase Supply
1600-000-U NSF/CSA Natural
110,000 BTU
32.2 kW
(116 MJ)
120 60 1 3
1633-000-E NSF/AGA/CE Natural 230 50 1 3
1635-V00-E -- Natural 220 60 1 5
1601-000-U NSF/CSA LP 120 60 1 3
1634-000-E NSF/AGA/CE LP 230 50 1 3
1636-V00-E -- LP 220 60 1 5
1621-000-E CE Electric
29 kW
400/230 50 3 5
1622-000-U UL/NSF Electric 120/208 60 3 5
1623-000-U UL/NSF Electric 120/240 60 3 5
1624-000-U UL/NSF Electric 120/220 60 3 5
1628-000-N -- Electric 380/220 50 3 5
1629-000-N -- Electric 415/240 50 3 5
1637-000-E CE Electric 215/240 50 3 5
NOTE: Panel setups are added as kit numbers to the end of the model number to complete the oven order; (example: 1600-000-U-K1819 is a 1600-000-U with
standard setup, left to right.)
