Automation System Selection Guide
Equipment
Robots (6
axes)
Positoners
Positioning
Systems
Custom
Systems
Options
Technical
Resources
ArcMate ®
100iBe & 120iBe
ArcMate ®
R2000-165F
System 50HP System 55 System 40
System 10
Workzone
Dimensions:
(2) - 610 X 610 mm
24” X 24”
Weight
Capacity:
113 kg/side
(250 lbs)
Footprint:
2286 x 1524 mm
(90” X 60”)
Payload:
6 kg (13.2 lbs)
Reach:
951 mm (37”)
Power Wave ® 355M
Processes:
MIG, Pulsed MIG,
Flux-Cored
Rated
Output:
350 Amps /
34 Volts /
60% Duty Cycle
Output
Range:
5-425 Amps
(eCell)
Processes:
MIG, Pulsed MIG,
Flux-Cored, STT®
(455M/STT Only)
Rated Output:
450 Amps /
38 Volts /
100% Duty Cycle
Output Range:
5-570 Amps
Power Wave ® 455M
& 455M/STT
Processes:
MIG, Pulsed MIG,
Flux-Cored
Rated
Output:
650 Amps /
44 Volts /
100% Duty Cycle
Output Range:
20-880 Amps
Power Wave ® 655R
Payload:
6 kg (13.2 lbs)
100iBe
20 kg (44.0 lbs)
120iBe
Reach:
1373 mm (54”) 100iBe
1167 mm (65”) 120iBe
Workzone
Dimensions:
(2) - 940 x 889 mm
(37” X 35”)
Weight
Capacity:
1134 kg/side
(2500 lbs)
Footprint:
3226 x 1753 mm
(127” X 69”)
eCell ™
Headstock H-Frame SkyHook Drop-Center Ferris Wheel
Hard Automation
Interface Options
RoboPipe
Process Pipe Welding
Dual Arm Horizontal Track Overhead Rail
Overhead Lengths
up to 28 m (90’)
Weldpro
Offline Programming Software
System 5
Procedure Development /
On-Site Programming Support
ArcMate ®
M710iC/20L
Payload:
20 kg (44.0 lbs)
Reach:
3110 mm (122”)
Fixed
Table
Systems
ArcMate ®
100iB-6S
ArcMate ®
120iB-10L
Payload:
10 kg (22.0 lbs)
Reach:
1885 mm (74”)
World Class Technical
Education Center
Fixtures, Tooling,
End-of-Arm Grippers and
Quality Assurance Tools
FANUC ® R-30iA
A-Cabinet
FANUC ® R-30iA
B-Cabinet
Payload:
165 kg (360.0 lbs)
Reach:
2660 mm (104”)
Payload:
907-2722 kg*
(2000-6000 lbs)
*supported load
Payload:
4535 kg (10000 lbs)
Span:
2286 mm (90”)
Swing
Diameter:
2286 mm (90”)
System 30 System 35
Workzone
Dimensions:
(2) - 914 x 1067 mm
36” X 42”
Weight
Capacity:
1134 kg/side
(2500 lbs)
Footprint:
4826 x 2032 mm
(190” X 80”)
Workzone
Dimensions:
(2) - 1981 x 991 mm
(78” X 39”)
Weight
Capacity:
1134 kg/side
(2500 lbs)
Footprint:
3912 x 3480 mm
(154” X 137”)
System 35W
24/7 Support
Arc Welding
Solutions Package
Servo Torch
S2f
Synchronized
Tandem MIG
Power Ream
Automatic Torch Cleaning
Environmental
Systems
System 30HS
Floor-Mounted Lengths
up to 18 m (60’)
Workzone
Dimensions:
1778 x 610 mm
(70” X 24”)
Weight
Capacity:
1134 kg/side
(2500 lbs)
Footprint:
3124 x 1753 mm
(123” X 69”)
Payload:
2267 kg (5000 lbs)
Span:
2388 mm (94”)
Swing
Diameter:
2388 mm (94”)
Analog Interface
Devicenet Gateway
(M710iC/20L)
A8 A12 A22 A30
Payload:
340-544 kg
(750-1200 lbs)
Span:
1016-2438 mm (40-96”)
Swing Diameter:
914-1016 mm (36-40”)
Payload:
454-1361 kg
(1000-3000 lbs)
Span:
1829-3658 mm (72-144”)
Swing Diameter:
1016-1829 mm (40-72”)
Workzone
Dimensions:
1803 mm Diameter
(71”)
Weight
Capacity:
340 kg/side
(750 lbs)
Footprint:
4928 X 2159 mm
(194” X 85”)
Workzone
Dimensions:
762 mm Span,
762 mm Swing (30”, 30”)
Weight
Capacity:
907-2721 kg/side
(2000-6000 lbs)
Footprint:
4572 X 2032 mm
(180” X 80”)
Workzone
Dimensions:
1371 mm Span,
1016 mm Swing (30”, 30”)
Weight
Capacity:
907-2721 kg/side
(2000-6000 lbs)
Footprint:
4902 X 2159 mm
(193” X 85”)
Workzone
Dimensions:
2133-2743 mm Span,
914 mm Swing
(84”-108”, 36”)
Weight
Capacity:
907-2721 kg/side
(2000-6000 lbs)
Footprint:
4521 X 3150 mm
(178” X 124”)
Workzone
Dimensions:
2133-3048 mm Span,
914-1219 mm Swing
(84”-120”, 36”-48”)
Weight
Capacity:
907-2721 kg/side
(2000-6000 lbs)
Footprint:
6782 X 4902 mm
(267” X 193”)
16 - 1143 mm, up to 18.3 m
(5/8” - 45”, up to 60’)
Single Teach Pendant Programming
Motion Types
• Independent
• Synchronized
• Mirror Image
Compatible with
all makes/models
of robots
• High Deposition Rates
• High Travel Speeds • Aluminum
• Soft Wires • Optimizes wrist motion
• Available as a retrofit kit
• Basic and Advanced Courses
• Customized Training
• Service School • Highest Customer Satisfaction
• Highest Perceived Value
as rated by Quality Solutions, Inc.
All dimensions subject to change without notice
