Datasheet – HD72
© Copyright 2006 Optoma Technology, Inc. DLP™ and the DLP™ logo are trademarks of Texas Instruments. All specifications subject to change at any time.
HD72 Home Theater Projector
Great Quality…Great Value…Great Performance
The Optoma HD72 projector is a true 720p, high-
performance home theater projector. The HD72 features
new technologies to deliver brighter images and truer
colors to the projected picture. The Optoma HD72 DLP™
home theater projector provides great color saturation
and subtle color details for the best image quality.
Features
 True High Definition 720p home theater projector
 Bright 1300 lumens with 5000:1 (ImageAI™ mode)
contrast ratio
 BrilliantColor™ technology by Texas Instruments
delivers higher brightness and more vibrant colors
 Native pixel-to-pixel matching for 720p HDTV and
4:3 XGA computer display
 ImageAI - Auto Adjusting light intensity output delivers
amazing contrast
 7 segment color wheel for detailed color reproduction
 Input connectors: DVI-I, HDMI, RCA component,
Composite, S-Video
 Light shield design and ultra-quiet 27 dB operation
Specifications
Brightness
1300 lumens (typical)
Resolution
1280x 768 native
UXGA (1600 x 1200), PC Max
1080p (1920 x 1080), Video Max
Contrast Ratio
5000:1 in ImageAI mode
3500:1 (full on/off)
Lamp Life
3000 hours STD
Display Type
Single 0.65-inch DarkChip2™ DLP™
technology by Texas Instruments
Throw Ratio
1.58 to 1.90 (distance/width)
Projection Distance
3.9’ to 39’
Image Size
28” to 304”
Noise Level
27 dB standard (typical)
Remote Control
22 Function IR Remote with direct
source selection
PC Compatibility
UXGA, SXGA+, WXGA, XGA, SVGA,
VGA compression; VESA standards;
PC and Macintosh compatible
Video Compatibility
HDTV (720p, 1080i, 1080p),
NTSC (M, 3.58/4.43 MHz),
PAL (B,D,G,H,I,M,N),
SECAM (B, D, G, K, K, K1, L) H
Projection Lens
F/2.5 ~ 2.8, f=22.25 ~ 26.69mm
1.2x zoom with manual focus;
digital zoom
User Controls
Advanced adjustability options
through the On-Screen Display
I/O Connection Ports
HDMI, DVI-I w/HDCP, component
video, composite video (RCA),
S-Video, RS-232, dual IR receivers,
+12V trigger relay
Weight
7 pounds (3.2 kg)
Dimensions (w x h x d)
13.56” x 3.72” x 9.67”
(344 x 94 x 246mm)
Operating Temperature
5 to 35 C°, 80% max humidity
Storage Temperatures
-20 to 60 C°, 80% max humidity
Power Supply
100-240 volts, 50 to 60 Hz
Power Consumption
285W, +/- 10% full power,
<13W standby power
Warranty
Limited 2 year with a Zero dead pixel
policy, 90-day lamp warranty
Standard Accessories
Composite video cable, S-video
cable, remote control, batteries for
remote control, lens cap, User’s
Manual, Quick Start Guide, warranty
card, power cord
Optional Accessories
Ceiling Mount kit, GrayWolf™ series
screens, carry case, extended
warranty and Gold Warranty service
options available
UPC
796435 11 589 0
HIGH-DEFINTION LIFESTYLE
