TECHNICAL SPECIFICATIONS - Vantage 575 (K2170-1)
INPUT - DIESEL ENGINE
Make /Model Description Speed (RPM) Displacement Starting Capacities
System
Cummins 4 cylinder High Idle 1590 3.3L 12VDC battery Fuel 94.6L
B3.3 36kw (48 HP) Low Idle 1300 (199 cu in) & Starter (25 US gal)
Diesel Engine @ 1500 RPM Full Load 1500
Bore x Stroke Oil: 7.5L
(2 US gal)
95mm x 115mm
(3.74” x 4.53”)
Coolant: 11.8L
(2.6 US gal)
RATED OUTPUT @ 40°C(104°F) - WELDER
Duty Cycle Welding Output Volts at Rated Amps
100% 450 Amps (DC multi-purpose) 38 Volts
60% 500 Amps (DC multi-purpose) 40 volts
PHYSICAL DIMENSIONS
Height (2) Width Depth Weight
1067mm 800mm 1603mm 737kg
(42.0 in) (31.5in) (63.1in) (1625lbs)
(Approx)
(CTE) Centre Tapped Earth
1.
Output rating in watts is equivalent to volt-amperes at unity power factor.
Output voltage is within +/- 10% at all loads up to rated capacity. When welding, available auxiliary power will be reduced.
2. Top of Enclosure. Add 223.5mm (8.8”) for exhaust.
OUTPUT @ 40°C(104°F) - WELDER AND GENERATOR
Welding Range
30 - 500 Amps CC/CV
20 - 250 Amps TIG
Open Circuit Voltage
60 Max OCV @ 1590 RPM
Auxiliary Power (1) (50 H Z )
Outlets x Phase Voltage Power Amps
1 x 3ph 380 Volt 12kVA 18.5 Amps
3 x 1ph 220 Volt 10kVA 15 Amps
A-1 INSTALLATION A-1
Vantage 575
