Service kit instructions – Life Fitness Next Generation Treadmills User Manual
Page 2
M051-00K58-A035
Service Kit Instructions
How To…Install Switch Bracket Assembly on Next Generation Treadmills
12.
Plug the 4-PIN DECLINE CABLE CONNECTOR to the LIFT/WAX PC BOARD.
13.
Plug the 4-PIN ACTUATOR CABLE to the LIFT/WAX PC BOARD and ACTUATOR
GROUND WIRE to the POWER BOX ENCLOSURE with a green GROUND SCREW.
14.
Attach the two short leads of the DECLINE CABLE to the HOME SWITCH LUGS (black wire
to the side lug, “COM”, and red wire to the top lug, “NO”)(as shown in Figure 2).
15.
Route the DECLINE CABLE along the ACTUATOR SUPPORT CHANNEL of the FRAME.
Secure all cables with Tiewrap cables.
