Life Fitness X30-0000-01 User Manual
Block diagram
LF Cross-Trainer
X30-0000-01
120V Dom. Eng/Eng
General Assembly
MOVEMENT ARMS
& HARDWARE
REAR
COMPONENTS
FRONT
COMPONENTS
CABLES
LF LOGO LABEL
REX2ARH
CONSOLE ASSEMBLY
REX2AXQ
ENDCAP
REX21MV
ENDCAP SCREWS
REX0KC6
CONSOLE DECAL
REX2AV7
WATER BOTTLE
REX2B96
WATER BOTTLE HOLDER
REX21CV
SCREWS
REX0K4R
BLOCK
DIAGRAM
OVERLAY
REX2AXM
MODEL BADGE
REX2AVN
HARDWARE BAG: REX2AZ8
TOUCH UP PAINT: 7967401
RECEIVER: REX21PV
TRANSMITTER: REX2B95
OPER. MANUAL: 7953401
GERMAN CONSOLE ASSEMBLY
REX2CTB
ACCESSORY TRAY: REX2AYF
CLEVIS COVERS
FRONT
REX2AQU
REAR
REX2AQT
rev. 07 May 07
