COMPONENT ASSEMBLY LEGEND ________________________________________
FWMAB FREE WEIGHT MULTI-ANGLE BENCH
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 7658501 ASSY, FWMAB BOTTOM FRAME
2 1 7661001 WLDMT, FWMAB FRONT LINK
3 1 7660501 ASSY, FWMAB SEAT
4 1 7661401 ASSY, FWMAB SEAT BACK
5 1 7659801 ASSY, FWMAB SPRING PIN TUBE
6 1 7660201 ASSY, FWMAB ADJ. ASM
7 1 U-FWMAB BENCH PAD
8 12 3103301 SHAFT COLLAR, 3/4 I.D. ZINC
9 1 8062201 SHAFT, FWMAB, REAR PIVOT
10 3 8062101 SHAFT, FWMAB, MAIN PIVOT
11 1 8062301 SHAFT, FWMAB, FRONT TOP
12 1 8062401 SHAFT, FWMAB, FRONT BOTTOM
13 2 7351001 SPACER, INC WT STACK
14 1 U33-19 STANDARD 33" PAD
15 8 3236601 WASHER, 3/8 SAE SS
16 8 3223302 3/8-16 X 1.25 HEX HEAD BOLT
