Technical information
Specifications
Output power
62W per channel into 8
1, 85W per channel into
(230 Vac mains)
4
1 (LK85)
95W per channel into 8
1, 140W per channel
into 4
1 (LK140)
Input signal for
685mV rms (LK85)
maximum output
870mV rms (LK140)
Maximum output
18.5V rms (LK85)
voltage
23.5V rms (LK140)
Gain
x27 (28.6dB)
Input impedance
10K
1
Frequency response
(-3dB) 10Hz–70kHz
Output offset
<5mV
Signal sense threshold >150μV rms
Standby power
<5W
consumption
Maximum input power 350W (LK85)
570W (LK140)
Fuse rating
115V: T6.3A
230V: T3.15A
100V model: T6.3A
Safety approvals
EN60065 (Europe), UL6500 (USA),
CSA-E65-94 (Canada)
EMC approval to European standards
Size
320mm x 325mm x 80mm
(12.6" x 12.8" x 3.1") (W x D x H)
Weight
7Kg (15.4lb)
