CASE, GEARING AND PLANETARY UNIT
5
For Models: KP26M1X_ _4, 4KP26M1X_ _4
8211764
Illus. Part
No. No. DESCRIPTION
1
Gearcase Motor
Housing
2
9707507 Motor (10 Tooth)
3
Cap, Attachment
Hub
9707983 Pearl Nickel
4
Thumb Screw
9709194 Black
9709196 Grey
5
Band, Trim
6
Power Cord
9706551 White
9706552 Black
7
9703671 Transmission
Housing
8
Control Assembly
(Incl. Knob)
9706648 Black Knob
9706649 Gray Knob
9
9703312 Sensor, Hall
Effect
10
9706090 Washer
11
9703434 Washer, Fiber
12
9707627 Gear, Pinion
13
9703438 Clip, Retaining
14
9708191 Shaft, Agitator
15
Planetary Assembly
16
16897 Bearing, Lower
Center
17
9709231 Gear, Worm
18
9707223 Pin, Retaining
19
9706529 Gear, Worm
Follower
20
9703338 Gear, Attachment
Hub Bevel
21
9703337 Gear, Bevel
22
3400617 Screw
23
3400814 Screw
24
Lower Gear Case
25
9703680 Clip, Retaining
27
3400200 Screw
28
Bearing
9703560 Front
9703570 Rear
29
9703445 Bearing, Thrust
30
67500−55 "O" Ring
31
9707425 Gasket,
Transmission Cover
32
9706036 Lead, Motor To
Control
33
9706247 Seal, Motor
Shaft
34
9703339 Gear, Internal
35
9704677 Pin, Groove
Refer To Page 3
Color Variation Parts
